Aims Power Power Inverter and Battery Charger, Pure Sine, 3,000 W Peak, 1,000 W Continuous, 2 Outlets PICOGLF10W12V120V - main

Power Inverter and Battery Charger, Pure Sine, 3,000 W Peak, 1,000 W Continuous, 2 Outlets

  • Mfr # PICOGLF10W12V120V

  • Zoro # G4430216

product price:  $799.99
/ea
Free Shipping & Returns

Key Features

Peak Output Power
3,000 W
Continuous Output Power
1,000 W
Inverter Output Form
Pure Sine
Inverter Input Voltage
12V DC
Inverter Output Voltage
100V/110V/120V AC
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
PICOGLF10W12V120V
Zoro #
G4430216
UPC #
840271003108
Country of Origin
China

Dimensions

Width
11"
Depth
15.35"
Height
7"
Length
16.25 in

Details

Item
Power Inverter and Battery Charger
Peak Output Power
3,000 W
Continuous Output Power
1,000 W
Inverter Output Form
Pure Sine
Inverter Input Voltage
12V DC
Inverter Output Voltage
100V/110V/120V AC
Outlet Type
GFCI / Hardwire
DC Connection
Battery Cables
Number of Outlets
2
Application
Home or business back-up power demands to campsites/cabins, tailgating parties or any recreational location
Includes
Inverter Charger
Features
Listed to UL 458 Standards and CSA 22.2 No 107.1, 1000 watt low frequency inverter, 3000 watt surge for 20 seconds -3x surge capability, Battery priority selector, AC direct connect terminal block, GFCI – 20 amps, Marine coated and protected, Multi stage smart charger 35 Amp for gel, AGM, lead and lithium LiFePO4 batteries, Remote panel available, Auto gen start, Auto frequency, 10msec typical transfer time, 7 battery type settings for charger, Selectable 25W power save mode (hibernation), Automatic transfer switch
Nominal Output Power
1,000 W
Standards
UL 1741-SA I CSA 22.2 No.107-01 I UL1998 I UL1699B
Inveter Output Voltage
Depends On Battery Type
Specification
Inverter Output Specifications: Input Specifications: Charger Specifications: Dimensions: ETL listed to UL 458 standards;Continuous Output Power: 1000 Watts;Surge Rating: 3000 Watts (20 Seconds);Output Waveform: Pure Sine/Same as input (Bypass Mode);Output Voltage: 100-110-120Vac;Nominal Efficiency: >92% (Peak);Line Mode Efficiency: >95%;Output Frequency: 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz;Bypass Breaker – 20 amps;Typical Transfer Time: 10ms (Max);THD: < 10% DC;Ambient Operating Temperature: 14°F to 122°F (-10°C to 50°C);Nominal Input Voltage: 12.0Vdc;Minimum Start Voltage: 10.0Vdc;Low Battery Alarm: 10.5Vdc-11.0Vdc;Low Battery Trip: 10.0Vdc-10.5Vdc;High Voltage Alarm: 16.0Vdc;Low Battery Voltage Restart: 13.0Vdc;Idle Consumption: 12.5 watts;Charger Breaker – 10 amps;Power Saver Mode Idle Consumption: 7.5 watts;Output Voltage: Depends on battery Type;Charger Rate: 35A;Unit Weight: 36.5 lbs.;Unit Size L x W x H: 15.35 x 11 x 7 inches;Shipping Weight: 44 lbs.;Shipping L x W x H: 20.5 X 13.8 X 12.2 inches
Color
Blue
Nominal Efficiency
>92% (Peak)
Output Waveform
Pure Sine/Same as input (bypass mode)
Output Voltage
100-110-120 VAC
Surge Rating
3,000 W

Description

Inverter Charger,Pure Sine,1000W
