Albion 4" X 2" Non-Marking Nylon Maxim Swivel Caster, Face Brake, Loads Up To 800 lb 16NG04201SFBA - main

4" X 2" Non-Marking Nylon Maxim Swivel Caster, Face Brake, Loads Up To 800 lb

  • Mfr # 16NG04201SFBA

  • Zoro # G8661430

product price:  $64.69
/ea

Key Features

Wheel Dia.
4 in
Number of Wheels
1
Wheel Width
2 in
Features
Brake, Harsh Environment Wheel, Heat Resistant Wheel, Kingpin, Medium Heavy Duty Caster
Mounting Bolt Dia.
3/8 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
16NG04201SFBA
Zoro #
G8661430
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
4 in
Wheel Width
2 in
Mounting Bolt Dia.
3/8 in
Swivel Radius
4 3/32 in
Mounting Height
5-5/8 in
Mounting Plate Thickness
1/4 in
Mounting Plate Size
4 in x 4 1/2 in
For Axle Dia.
1/2 in
Hub Length
2 3/16 in
Outside Slot Spacing - Width
3 in
Inside Slot Spacing - Width
2.625 in
Outside Slot Spacing - Length
3.625 in
Mounting Plate Width
4 in
Mounting Plate Length
4 1/2 in
Inside Slot Spacing - Length
3 in

Details

Number of Wheels
1
Features
Brake, Harsh Environment Wheel, Heat Resistant Wheel, Kingpin, Medium Heavy Duty Caster
Frame Finish
Zinc Plated
Core Color
Black
Caster Plate Hole Pattern
B
Caster Frame Material
Steel
Caster Sub-Type
Swivel
System of Measurement
Inch
Non-Marking
Yes
Caster Brake Type
Side Brake
Standards
NSF Listed, RoHS Compliant
Load Rating
800 lb
Application
Distribution Carts, Dollies, Floor Trucks, Platform Trucks, Warehouse Trucks, Waste Disposal Trucks
Caster Mounting Type
Plate
Item
Swivel with Face Brake
Outside Bolt Hole Spacing
3 in X 3-5/8 in
Inside Bolt Hole Spacing
2-5/8 in X 3 in
Wheel/Tread Color
Black
Wheel Bearing Type
Roller
Includes Thread Guards
No
Operating Temperature Range
-40 Degrees to +250 Degrees F
Wheel Core Material
Nylon
Wheel/Tread Hardness Rating
Hard
NSF Listed
Yes
Number of Mounting Holes
4
With Toe Plate
No
Swivel Lock Type
No Lock Included
Tread Shape
Donut
Frame Construction
Cold Forged
Wheel Core Type
Solid
Swivel Construction
Kingpin
Swivel Lead
1 11/16 in
Wheel/Tread Material
Nylon
Swivel Raceway Type
Double Ball
Load Rating Range
300 to 999 lb
Includes Spanner Bushing
Yes
Load Capacity - Maximum
800 lb
Wheel Hardness Rating
85 Shore D
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel, Tile, Wood
Brake Location
Left Side

Description

Swivel, Plate Caster, Load Rating 800 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Nylon, Wheel Core Material Nylon, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Side Brake, Tread Shape Donut
