  6. 4" X 2" Non-Marking Nylon Maxim Swivel Caster, Total Lock Brake, Loads Up To 800 lb
Albion 4" X 2" Non-Marking Nylon Maxim Swivel Caster, Total Lock Brake, Loads Up To 800 lb 16NG04201ST - main

4" X 2" Non-Marking Nylon Maxim Swivel Caster, Total Lock Brake, Loads Up To 800 lb

  • Mfr # 16NG04201ST

  • Zoro # G900712802

product price:  $98.99
/ea
Free Shipping & Returns

Key Features

Core Color
Black
Number of Mounting Holes
4
Mounting Height
5-5/8 in
Swivel Lead
1 11/16 in
Swivel Raceway Type
Double Ball
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
16NG04201ST
Zoro #
G900712802
UPC #
-
Country of Origin
United States

Dimensions

Mounting Height
5-5/8 in
Wheel Dia.
4 in
Swivel Radius
6 9/16 in
For Axle Dia.
1/2 in
Mounting Bolt Dia.
3/8 in
Mounting Plate Thickness
1/4 in
Mounting Plate Size
4 in x 4 1/2 in
Wheel Width
2 in
Hub Length
2 3/16 in
Inside Slot Spacing - Length
3 in
Outside Slot Spacing - Length
3.625 in
Outside Slot Spacing - Width
3 in
Mounting Plate Width
4 in
Inside Slot Spacing - Width
2.625 in
Mounting Plate Length
4 1/2 in

Details

Core Color
Black
Number of Mounting Holes
4
Swivel Lead
1 11/16 in
Swivel Raceway Type
Double Ball
Caster Plate Hole Pattern
B
Swivel Lock Type
No Lock Included
Caster Frame Material
Steel
Caster Brake Type
Total Lock
Wheel/Tread Hardness Rating
Hard
Non-Marking
Yes
With Toe Plate
No
Wheel Bearing Type
Roller
Wheel/Tread Color
Black
Caster Mounting Type
Plate
Swivel Construction
Kingpin
Number of Wheels
1
Operating Temperature Range
-40 Degrees to +250 Degrees F
Inside Bolt Hole Spacing
2-5/8 in X 3 in
Caster Stem Type
Top Plate
Wheel Core Material
Nylon
Features
Brake, Harsh Environment Wheel, Heat Resistant Wheel, Kingpin, Medium Heavy Duty Caster
Application
Distribution Carts, Dollies, Floor Trucks, Platform Trucks, Warehouse Trucks, Waste Disposal Trucks
Outside Bolt Hole Spacing
3 in X 3-5/8 in
Caster Sub-Type
Swivel
Standards
NSF Listed, RoHS Compliant
System of Measurement
Inch
Frame Construction
Cold Forged
Load Rating
800 lb
Tread Shape
Donut
Includes Thread Guards
No
Item
Swivel with Total Lock Brake
NSF Listed
Yes
Wheel/Tread Material
Nylon
Frame Finish
Zinc Plated
Wheel Core Type
Solid
Load Rating Range
300 to 999 lb
Includes Spanner Bushing
Yes
Load Capacity - Maximum
800 lb
Wheel Hardness Rating
85 Shore D
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
Brake Location
Face
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel, Tile, Wood

Description

Swivel, Plate Caster, Load Rating 800 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Nylon, Wheel Core Material Nylon, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Total Lock, Tread Shape Donut
