  11. 4" X 2" Non-Marking Polyurethane Swivel Caster, No Brake, Loads Up To 700 lb
Albion 4" X 2" Non-Marking Polyurethane Swivel Caster, No Brake, Loads Up To 700 lb 16XA04201S - main

4" X 2" Non-Marking Polyurethane Swivel Caster, No Brake, Loads Up To 700 lb

  • Mfr # 16XA04201S

  • Zoro # G7239304

product price: $55.19
/ea

Key Features

Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Polyurethane
Caster Brake Type
No Brake
Wheel Dia.
4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
16XA04201S
Zoro #
G7239304
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
4 in
Wheel Width
2 in
Mounting Height
5-5/8 in
Mounting Plate Size
4 in x 4 1/2 in
Mounting Plate Thickness
1/4 in
Mounting Bolt Dia.
3/8 in
Hub Length
2 3/16 in
Outside Slot Spacing - Length
3.625 in
Mounting Plate Length
4 1/2 in
Outside Slot Spacing - Width
3 in
For Axle Dia.
1/2 in
Inside Slot Spacing - Width
2.625 in
Mounting Plate Width
4 in
Inside Slot Spacing - Length
3 in

Details

Item
Swivel Caster
Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Polyurethane
Caster Brake Type
No Brake
Load Rating
700 lb
Caster Mounting Type
Plate
Wheel Bearing Type
Roller
Wheel/Tread Color
Grey
Wheel Hardness Rating
55 Shore D
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Grey
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
3 in X 3-5/8 in
Inside Bolt Hole Spacing
2-5/8 in X 3 in
Caster Plate Hole Pattern
B
Frame Finish
Zinc Plated
Caster Stem Type
Top Plate
Application
Shop/Distribution Carts, Dollies, Waste Disposal Trucks, Warehouse Trucks, Floor Trucks
Swivel Lead
1 11/16 in
Series
16 Series HD
Frame Color
Silver
Swivel Raceway Type
Precision Ball
Swivel Construction
Kingpin
Wheel Core Material
Polypropylene
Includes Thread Guards
No
Wheel Bearing Material
Roller
Wheel/Tread Hardness Rating
Hard
Load Rating Range
300 to 999 lb
Operating Temperature Range
-40 Degrees to 180 Degrees F
Load Capacity - Maximum
600 lb
Mounting Hole Type
Slot
Wheel Core Type
Solid
For Surface Type
Asphalt, Grease, Steel, Tile
Mounting Plate Shape
Rectangle

Description

Swivel, Plate Caster, Load Rating 600 lb, Wheel Dia. 4 in, Wheel Width 2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Polypropylene, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
