8" X 2-1/2" Rubber Pneumatic Swivel Caster, Face Contact Brake, Loads Up To 220 lb

  • Mfr # 16SF08427SF

  • Zoro # G100719830

product price:
$
284.99
/ea
Free Shipping & Returns

Key Features

Number of Mounting Holes
4
Caster Brake Type
Face Brake
Caster Frame Material
Steel
Wheel/Tread Hardness Rating
Not Rated
Frame Finish
Zinc Plated
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
16SF08427SF
Zoro #
G100719830
UPC #
-
Country of Origin
United States

Dimensions

Tire Rim Dia.
3 in
Wheel Width
2 1/2 in
Mounting Height
9 1/2 in
Mounting Bolt Dia.
3/8 in
Wheel Dia.
8 in
Mounting Plate Size
4 in x 4 1/2 in
For Axle Dia.
1/2 in
Inside Slot Spacing - Length
3 in
Mounting Plate Thickness
1/4 in
Mounting Plate Width
4 in
Outside Slot Spacing - Length
3.625 in
Outside Slot Spacing - Width
3 in
Mounting Plate Length
4 1/2 in
Inside Slot Spacing - Width
2.625 in

Details

Number of Mounting Holes
4
Caster Brake Type
Face Brake
Caster Frame Material
Steel
Wheel/Tread Hardness Rating
Not Rated
Frame Finish
Zinc Plated
Load Rating Range
0 to 299 lb
Wheel Type
Pneumatic
Swivel Construction
Kingpin
Tread Color
Black
Caster Mounting Type
Plate
Wheel/Tread Material
Rubber
Wheel Bearing Type
Ball
Non-Marking
No
Number of Wheels
1
Includes Thread Guards
No
Operating Temperature Range
Not Rated
Tread
Centipede
Includes
Assembly Components, Axle, Rig, Wheel
Inside Bolt Hole Spacing
7 5/8 in x 3 in
Replacement Wheel
Mfr. No. SF0822708
Item
Plate Caster
Swivel Raceway Type
Double Ball
Load Rating
220 lb
Wheel Core Material
Steel
Swivel Lock Type
No Lock Included
Application
Material Handling, Utility Carts
Features
Cushioned Ride, Protects Floor, Shock Absorbing
Outside Bolt Hole Spacing
3 in x 3 5/8 in
Core Color
Silver
Caster Plate Hole Pattern
B
Caster Sub-Type
Swivel
Tread Shape
Standard
Load Capacity - Maximum
220 lb
Brake Location
Face
Mounting Hole Type
Slot
Wheel Core Type
Solid
For Surface Type
Asphalt, Ceramic, Rubber, Steel, Tile, Wood
Mounting Plate Shape
Rectangle

Description

Swivel, Plate Caster, Load Rating 220 lb, Swivel Lock Type No Lock Included, Wheel Dia. 8 in, Wheel Width 2 1/2 in, Wheel/Tread Material Rubber, Wheel Core Material Steel, Non-Marking No, Number of Wheels 1, Caster Brake Type Face Brake, Tread Shape Standard
