Shop ALBION

8" X 2" Non-Marking Elastomer Swivel Caster, Face Brake, Loads Up To 1200

  • Mfr # 16SE08228SFBA
  • Zoro # G000712962
product price:
$
137.99
/ea
Free Shipping & Returns

Key Features

Wheel/Tread Hardness Rating
Hard
Wheel Dia.
8 in
Outside Bolt Hole Spacing
3 in x 3 5/8 in
Application
Distribution Carts, Dollies, Floor Trucks, Platform Trucks, Warehouse Trucks, Waste Disposal Trucks
Caster Mounting Type
Plate
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Details

MFR #
16SE08228SFBA
Zoro #
G000712962
UPC #
-
Country of Origin
United States
Wheel/Tread Hardness Rating
Hard
Outside Bolt Hole Spacing
3 in x 3 5/8 in
Application
Distribution Carts, Dollies, Floor Trucks, Platform Trucks, Warehouse Trucks, Waste Disposal Trucks
Caster Mounting Type
Plate
Tread Shape
Donut
Frame Construction
Cold Forged
Swivel Lead
1 3/4 in
Number of Mounting Holes
4
Inside Bolt Hole Spacing
2 5/8 in x 3 in
Core Color
Gray
With Toe Plate
No
Caster Frame Material
Steel
Number of Wheels
1
Caster Plate Hole Pattern
B
Caster Sub-Type
Swivel
Item
Plate Caster
Wheel Bearing Type
Ball
Frame Finish
Zinc Plated
Swivel Raceway Type
Double Ball
Wheel Core Material
Polyurethane
Includes Thread Guards
No
Non-Marking
Yes
Caster Brake Type
Side Brake
System of Measurement
Inch
Wheel/Tread Color
Gray
Wheel/Tread Material
Polyurethane
Wheel Core Type
Solid
Features
Brake, Harsh Environment Wheel, Kingpin, Medium Heavy Duty Caster, USA-Made Wheel
Swivel Lock Type
No Lock Included
Load Rating
1200 lb
Swivel Construction
Kingpin
Operating Temperature Range
Up to +230 Degrees F
Includes Spanner Bushing
No
Load Rating Range
1000 to 2999 lb
Load Capacity - Maximum
1,200 lb
Wheel Hardness Rating
63 Shore D
Brake Location
Left Side
Mounting Hole Type
Slot
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel, Tile, Wood
Mounting Plate Shape
Rectangle

Dimensions

Wheel Dia.
8 in
Mounting Bolt Dia.
3/8 in
For Axle Dia.
1/2 in
Swivel Radius
5 3/4 in
Mounting Height
9 1/2 in
Wheel Width
2 in
Mounting Plate Thickness
1/4 in
Mounting Plate Size
4 in x 4 1/2 in
Hub Length
2 3/16 in
Mounting Plate Width
4 in
Outside Slot Spacing - Length
3.625 in
Inside Slot Spacing - Width
2.625 in
Inside Slot Spacing - Length
3 in
Outside Slot Spacing - Width
3 in
Mounting Plate Length
4 1/2 in
Fits Chest Size
Brake, Harsh Environment Wheel, Kingpin, Medium Heavy Duty Caster, USA-Made Wheel

Description

Swivel, Plate Caster, Load Rating 1200 lb, Swivel Lock Type No Lock Included, Wheel Dia. 8 in, Wheel Width 2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Polyurethane, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Side Brake, Tread Shape Donut
