  9. Y Strainer, 316 SS, 1-1/2", 200 Mesh
Shop All Filter Housings
Amiad

Y Strainer, 316 SS, 1-1/2", 200 Mesh

product price: $72.15
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Housing Material Acetal
  • Height 10 3/4 in
  • Screen Material 316 Stainless Steel
  • Mesh 200
  • Flow Rate 60 gpm
See all product information

Product Information

Dimensions

Height 10 3/4 in
Length 12 in
Width 11 7/8 in
Pipe Size 1 1/2 in
Mesh Size 12 mesh
Port 3 Connection Size 3/4 in
Port 1 Connection Size 1 1/2 in
Port 2 Connection Size 1 1/2 in

Details

Housing Material Acetal
Screen Material 316 Stainless Steel
Mesh 200
Flow Rate 60 gpm
Blow-off Port 3/4 in
Gasket Material NBR
Item Y Strainer
Max. Fluid Temp. 140 Degrees F
Screen Area 52.7 sq in
Max. Pressure 150 psi
Connection Type NPT
Microns 80
Micron Rating 80 micron
Maximum Temperature 140 Degrees F
Seal Material NBR
Port 3 Connection Type NPT
Maximum Pressure 150 psi
Strainer Type Mesh
Includes Screen No
Port 2 Connection Type NPT
Blow Off Port 3/4 in
Maximum Pressure at 100 deg F 150 psi @ 140 Degrees F
Port 1 Connection Type NPT

Description

Y Strainer, Pipe Size 1 1/2 in, Maximum Pressure at 100 deg F 150 psi @ 140 Degrees F, Length 12 in, Height 10 3/4 in, Blow Off Port 3/4 in, Screen Material 316 Stainless Steel, Mesh Size 12 mesh, Housing Material Acetal, Flow Rate 60 gpm, Includes Screen No, Maximum Pressure 150 psi, Maximum Temperature 140 Degrees F, Micron Rating 80 micron, Port 1 Connection Size 1 1/2 in, Port 1 Connection Type NPT, Port 2 Connection Size 1 1/2 in, Port 2 Connection Type NPT, Port 3 Connection Size 3/4 in
