Contact our U.S. based teamSpecifications
Product Information
MFR #
284541-8
Zoro #
G300930042
UPC #
-
Country of Origin
Italy
Dimensions
PCB Tail Length
3.4 mm [ .134 in ]
Details
Number of Positions
8
Centerline
3.81 mm [ .1499 in ]
Stacked Levels
Without
Housing Material
Polyamide 6.6
Screw Flange
Without
Contact Mating Area Plating Material
Tin
Threaded Flange
With
Side Stackable
No
Interlock
Without
Block Type
None
Screwless Terminal Block
No
Connector Style
Header
Mounting Angle
Right Angle
Closed End
With
Mating Angle
90°
Contact Base Material
Phosphor Bronze
Number of Rows
1
Shrouded
Yes
Voltage (VAC)
300
Applies To
Printed Circuit Board
Contact Mount
Through Hole
Housing Color
Green
Current Rating (Max) (A)
11
Description
