Product Information
MFR #
5-160447-4
Zoro #
G801018058
UPC #
-
Country of Origin
Italy
Dimensions
Wire Size
17 - 13 AWG
Overall Length
.799 in
Accepts Wire Insulation Diameter Range
.118 - .138 in
Receptacle Stock Thickness
.016 in
Mating Tab Width
.25 in
Mating Tab Thickness
.032 in
Details
Terminal Type
Receptacle
Barrel Type
Open
Disconnect Type
Quick Disconnect
Voltage (Max)
250 V
Contact Base Material
Brass
Wire/Cable Type
Regular Wire
Terminal & Splice Style
Receptacle
UL Flammability Rating
UL 94V-2
Mating Retention Type
Locking Lance
Terminates To
Wire & Cable
Terminal Orientation
Straight
Fully Insulated
No
Connection Capacity
Single
Wire Insulation Support
With
Insertion Force
Normal
Crimp Type
F-Crimp
FASTON
Yes
Plating Material
Unplated
