Product Information
MFR #
1571983-8
Zoro #
G700945271
UPC #
-
Country of Origin
China
Dimensions
Length
.344 in
Details
Housing Material
Polyphenylene Sulfide (PPS)
Voltage Rating
50 VDC
Actuator Style
Recessed Rocker
Contact Base Material
Copper Alloy
Solder Tail Contact Plating
Gold over Nickel
Termination Style
Outside L
UL Flammability Rating
UL 94V-0
Housing Color
Black
Mounting Type
Surface Mount
Number of Positions
6
Configuration (Pole-Throw)
Single Pole - Single Throw
Number of Switches
6
Centerline
.05 in
Contact Current Rating
.1 A
Contact Mating Area Plating Material
Gold
Operating Temperature Range
-30 to 85°C
Low Profile
Yes
Auto-Insertable
No
Sealed
Yes
Product Type
Switch
Seal Type
Tape
Switch Type
DIP
