Product Information
MFR #
1-1825013-0
Zoro #
G700965804
UPC #
-
Country of Origin
Japan
Details
Centerline
2.54 mm [ .1 in ]
Housing Material
Thermoplastic
Illuminated
No
Number of Positions
10
Number of Switches
10
Mounting Angle
Right Angle
Contact Current Rating (A)
0.001
Solder Tail Contact Plating
Gold over Nickel
Product Type
Switch
Sealed
Yes
Code Type
BC Decimal
Contact Mating Area Plating Material
Gold
Termination Style
Outside L
Actuator Color
Red
Switch Style
Rotary
Switch Type
Rotary DIP
Mounting Type
Surface Mount
Contact Base Material
Copper Alloy
Voltage Rating
20 VAC [ 20 VDC ]
Actuator Style
Flush
UL Flammability Rating
UL 94V-0
