Amprobe Underground Utility Locator, 20 ft Max D UAT-620 - main

Underground Utility Locator, 20 ft Max D

  • Mfr # UAT-620

  • Zoro # G7496238

product price: $7,185.99
/ea
Free Shipping & Returns

Key Features

Includes
Carrying Case, Replacement Fuses, Signal Clamp, Transmitter
Features
Multiple Tracing Modes Allow you to Locate and Trace Energized and De-Energized Utilities, Receiver's High-Contrast Display Allows for Clear Viewing in Full Sunlight and Features An Automatic Backlight for Shaded and Dark Area
Operating Frequency
50 Hz, 60 Hz
Power Source
Battery
Display
LCD
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
UAT-620
Zoro #
G7496238
UPC #
095969873710
Country of Origin
China

Dimensions

Manufacturers Warranty Length
1 yr
Depth Underground
20 ft
Receiver Dimensions
30.7 in x 4.7 in x 11.9 in
Battery Size
AA
Transmitter Dimensions
4.7 in x 9 in x 14 in
Manufacturer Warranty Length
1 yr
Maximum Locating Depth
20 ft

Details

Item
Underground Utility Locator
Includes
Carrying Case, Replacement Fuses, Signal Clamp, Transmitter
Features
Multiple Tracing Modes Allow you to Locate and Trace Energized and De-Energized Utilities, Receiver's High-Contrast Display Allows for Clear Viewing in Full Sunlight and Features An Automatic Backlight for Shaded and Dark Area
Operating Frequency
50 Hz, 60 Hz
Power Source
Battery
Display
LCD
For Use On
Energized/Unenergized Lines
Voltage Range
0/600V DC
Receiver to Transmitter Distance
20 ft
Audible Alert
Yes
Voltage Protection
600V DC
Coupling
Direct and Inductive
Battery Type
(6) AA Receiver, (8) D Transmitter
Inductive Frequencies
33 kHz (Transmitter)
For Circuit Type
Energized Lines, Non-Energized Lines
Circuit Connection Type
Direct, Induction
Line Trace Frequencies
33 kHz, 8 kHz
For Locating
Energized Cables
CAT Safety Rating
CAT IV 600V
For Voltage Range
0 to 600V
Testing Modes
Active/Passive with Transmitter
Standards
CSA, IEC 61010-1, IEC 61010-2-033, UL 61010-1
Transmitter Power Output
3 W
Alert Type
Sound
Sonde Frequencies
33 kHz, 8 kHz
Display Type
Digital
Display Screen Type
LCD
IP Rating
IP54
Battery Chemistry
Alkaline
Locator Type
Utility Line Locator Kit (Transmitter & Receiver)
Compatible Receiver
Amprobe UAT-620
Includes Batteries
Yes

Description

Underground Utility Locator, CAT Safety Rating CAT IV 600V, Circuit Connection Type Direct, Induction, Features Multiple Tracing Modes Allow you to Locate and Trace Energized and De-Energized Utilities, Receiver's High-Contrast Display Allows for Clear Viewing in Full Sunlight and Features An Automatic Backlight for Shaded and Dark Area, For Locating Energized Cables
