SPRING HANGERS 1 LOAD RANGE 350-525LBS
Mfr # SHD-107
Zoro # G408458370
product price: $54.25
/eaSold in multiples of 4 for $217.00
Key Features
Width
2.25"
Height
5.5"
Spring Color
Silver
Includes
Steel Spring, Steel Bracket, Neoprene Cup, Steel and Elastomer Washers
Application
These spring hangers are normally used in critical areas where noise and vibration need to be controlled
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
SHD-107
Zoro #
G408458370
UPC #
-
Country of Origin
Canada
Dimensions
Width
2.25"
Height
5.5"
Length
3"
Details
Item
Spring Hanger
Spring Color
Silver
Includes
Steel Spring, Steel Bracket, Neoprene Cup, Steel and Elastomer Washers
Application
These spring hangers are normally used in critical areas where noise and vibration need to be controlled
Color
Blue (Powder Coated)
Material
Spring Steel; High Strength Low Carbon Alloy Steel; Elastomeric Compounds; Powder Coating
For Use With
Fan Coil Units, Air Handling Units, Fans, Pipes, Ducts
Finish
Spring: Galvanized; Bracket: Powder Coated
Rated Deflection
1"
Max Load
700lbs
Capacity
462lbs
Rated Load
700LBS
Spring Identifier Color
Green
Features
Design allows angular hanger misalignment. Springs have 50% additional travel to max load as per ASHRAE recommendations. The assembly incorporates dual (Steel and Elastomer) washers for uniform load distribution and high frequency isolation
Description
SPRING HANGERS
