  11. Power Strip, Surge, L5-15R, L5-15P, 12 ft., Black
Apc Power Strip, Surge, L5-15R, L5-15P, 12 ft., Black AP7800B - main

Power Strip, Surge, L5-15R, L5-15P, 12 ft., Black

  • Mfr # AP7800B

  • Zoro # G6584322

product price: $568.99
/ea
Free Shipping & Returns

Key Features

Type
Surge
Receptacle Configuration
L5-15R
Plug Configuration
L5-15P
Cord Length
12 ft.
Color
Black
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AP7800B
Zoro #
G6584322
UPC #
731304331452
Country of Origin
Philippines

Dimensions

Cord Length
12 ft.
Height
1 3/4 in
Length
17 15/32 in
Width
13 1/4 in
Depth
10.2 cm
Dimensions
10.2 cm D x 4.4 cm H x 44.4 cm W
Length (Straight Wireway)
17 15/32 in
Overall Height
1 3/4 in
Overall Width
17 1/2 in
Overall Length
17 1/2 in
Manufacturers Warranty Length
2 yr

Details

Item
Power Strip
Type
Surge
Receptacle Configuration
L5-15R
Plug Configuration
L5-15P
Color
Black
Standards
CSA, cUL Listed, FCC Part 15 Class A, ICES-003, METI Denan, UL 60950, UL Listed, VCCI
GFCI Protected
No
Includes
Cord Retention Brackets, Mounting Brackets
Outlet Surge Protection
No
Circuit Breaker
No
Power Indicator
Yes
Phase
Single
Mounting Style
Horizontal Rackmount/1U
Max. Amps
15A
Receptacle Type
NEMA 5-15R
Housing Material
Steel and Plastic
Number of Outlets
8
Plug Type
NEMA 5-15P
Voltage
120V
Metered
Metered
Hz
50/60 Hz
NEMA Receptacle Configuration
NEMA 5-15R
NEMA Plug Configuration
NEMA 5-15P
Built-In Circuit Breaker
No
Rack Units
1
Maximum Input Voltage
120V AC
Maximum Current
15 A
Maximum Output Voltage
120V AC
Maximum Operating Temperature
113 Degrees F
Minimum Operating Temperature
23 Degrees F
Receptacle Detail
8 x NEMA 5-15R
PDU Type
Metered
Input Current
15 A
Frequency
50/60 Hz
Input Voltage
100 V AC
Package Contents
Rack PDU, Metered, 1U, 15A, 100/120V, (8) 5-15 , Cord retention bracket(s), Installation guide, Rack mounting brackets, User manual
Output Voltage
120 V AC
Certifications & Standards
cUL Listed
Mount Type
Rack-mountable

Description

Power Distribution Unit, Built-In Circuit Breaker No, Color Black, Cord Length 12 ft, Number of Outlets 8, Receptacle Type NEMA 5-15R, Maximum Input Voltage 120V AC, Outlet Surge Protection No, Metered Metered, Rack Units 1, Mounting Location Horizontal Rack, Plug Type NEMA 5-15P, Housing Material Plastic, Includes Cord Retention Brackets, Mounting Brackets, Manufacturers Warranty Length 2 yr, Maximum Current 15 A, Maximum Operating Temperature 113 Degrees F, Maximum Output Voltage 120V AC
