- Item
- UPS System
- VA Rating - UPS Systems
- 2.88 kVA
- UPS Type
- Line Interactive
- Power Rating
- 3000VA
- Mounting
- Rack/Tower
- Wattage
- 2.7 kW
- Input Voltage
- 120V AC
- Output Voltage
- 120V AC
- Backup Time (Half/Full Load)
- 18 min/6.3 min
- Outlet Type
- UPS/Surge
- Medical Grade
- No
- Number of Outlets
- 10
- Input Current
- 24 A
- Hz
- 50/60 Hz ( +/-3 Hz)
- NEMA Receptacle Configuration
- (1) L5-30R; (3) 5-20R; (6) 5-15R
- Display Type
- LCD/LED
- Ports
- EPO, RJ45 10/100Base-T, RJ45 Serial, Smart Slot, USB
- Transfer Time
- 4 to 8 msec
- Phase
- Single
- NEMA Plug Configuration
- L5-30P
- Standards
- BSMI, CSA, NOM, RoHS, VCCI Class A
- Fax/Modem Line Protection
- No
- Automatic Volts Regulation
- Yes
- Includes
- Rack Mounting Brackets, Rack Mounting Hardware, Rack Mounting Support Rails, Removable Support Feet, Smart UPS Signalling RS-232 Cable, USB Cable, Web/SNMP Management Card
- Housing Color
- Black
- Battery Type
- Sealed Lead Acid (SLA)
- Capacity - Batteries
- 2880 VA/2700 W
- Housing Material
- Steel
- Other Output Voltages
- 100 V || 110 V || 127 V
- Efficiency At Full Load
- 70...153 V
- Ambient Air Temperature For Operation
- 0-40°C
- Operating Altitude
- 0...10000 ft
- Rated Power In Va
- 2880 VA
- Usb Compatible
- Yes
- Number Of Rack Unit
- 4U
- Kw Rating
- 2700 W
- Relative Humidity
- 0-95 %
- Online Thermal Dissipation
- 276 Btu/h
- Number Of Cables
- 1
- Maximum Output Current
- 15 A
- Other Input Voltages
- 100 V || 110 V || 127 V
- Harmonic Distortion
- Less than 5%
- Storage Altitude
- 0-50000 ft
- Input Frequency
- 50/60 Hz +/- 3 Hz auto-sensing
- Mounting Location
- front
- Presentation
- Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.
- Ambient Air Temperature For Storage
- -15-45°C
- Provided Equipment
- CD with software || Documentation CD || Installation guide || Rack mounting hardware || Rack Mounting brackets || Rack Mounting support rails || Removable support feet || Smart UPS signalling RS-232 cable || USB cable || Web/SNMP Management Card
- Acoustic Level
- 55 dBA
- Free Slots
- 0
- Battery Life
- 3-5 year(s)
- Alarm
- alarm when on battery : distinctive low battery alarm : configurable delays
- Control Panel
- LED status display with on line : on battery : replace battery and overload indicators, Multi-function LCD status and control console
- Product Certifications
- BSMI || CSA || NOM || TUV || VCCI Class A
- Additional Specification
- network card pre-installed
- Battery Characteristics
- Spill-proof, Maintenance-free
- Serial Port
- Yes
- Number of Battery & Surge Outlets
- 10
- Load Capacity
- 2880 VA/2700 W
- USB
- Yes
- Form Factor
- Rack-mountable
- Waveform Type
- Sine Wave
- Network Management
- SNMP Manageable
- Package Contents
- Smart-UPS X 3000VA Rack/Tower LCD 100-127V with Network Card , CD with software, Documentation CD, Installation guide, Rack mounting brackets, Rack mounting hardware, Rack mounting support rails, Removable support feet, Smart UPS signalling RS-232 cable, USB cable, Web/SNMP management card
- Typical Battery Recharge Time
- 3 Hour
- Emergency Power OFF
- Yes
- Battery Chemistry
- Valve Regulated Lead Acid
- Number of Batteries
- 1
- Hot Swappable
- Yes
- Surge Energy Rating
- 540 J
- Includes Battery
- Battery Included
- Manufacturer Warranty
- 3 yr
- Battery Recharge Time
- 3 hr
- Receptacle Configuration
- 5-15R, 5-20R, L5-20R
- Audible Alarm Conditions
- Low Battery
- Automatic Voltage Regulation
- Includes Automatic Voltage Regulation
- Operating Temperature - Maximum
- 104 Degrees F
- Output Ports Included
- RS-232, SNMP, USB
- Power Rating - Real
- 2.7 kW
- Number of Outlets - UPS
- 10
- Battery Life - Minimum
- 3 yr
- External Battery Pack Part Number
- SMX120BP
- Replacement Battery Part Number
- APCRBC143
- Power Rating - Apparent
- 3 kVA
- External Battery Compatible
- External Battery Pack Compatible
- Run Time - Full Load
- 6.25 min
- Frequency
- 50/60 Hz
- Transfer Time - Minimum
- 4 msec
- Surge Suppression Rating
- 540 J
- Plug Configuration
- L5-30P
- Input Current - Maximum
- 24 A
- Operating Temperature - Minimum
- 32 Degrees F
- Transfer Time - Maximum
- 8 msec
