Appleton Electric Legend Plate, Test, White/Black LNPTESTQ - main

Legend Plate, Test, White/Black

  • Mfr # LNPTESTQ

  • Zoro # G0118192

product price: $16.49
/ea

Key Features

Material
Aluminum
Color
Black, White Letters
Legend
Test
Legend/Background Color
White/Black
Operator Size
30 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
LNPTESTQ
Zoro #
G0118192
UPC #
-
Country of Origin
United States

Dimensions

Operator Size
30 mm
Compatible Panel Cutout Diameter
30 mm

Details

Item
Legend Plate
Material
Aluminum
Color
Black, White Letters
Legend
Test
Legend/Background Color
White/Black
Shape
Half-Round
For Use With
EFD and EFDB Control Stations
Product Type
Legend Plate
N1 Series NEC Certifications and Compliances
Class I, Division 1 and 2, Groups C, D; NEMA 3R, 4X, 7CD, 12
SSBA Standard Materials and Finishes
Selector switch operator mechanism is copperfree (4/10 of 1% max.) aluminum with a natural finish; nylon cam; and sealed phenolic contact block
N1 and N1 Standard Materials and Finishes
30% glass-reinforced thermoplastic polyetherimide. Teflon coated stainless steel cover bolts and Mylar nameplates.
N2 Series NEC Certifications and Compliances
Class I, Division 2, Groups B, C, D; Class II, Division 1 and 2, Groups E, F, G; Class III; NEMA 3R, 4X, 9EFG, 12
SPBB Standard Materials and Finishes
Push button upper barrel is copperfree (4/10 of 1% max.) aluminum with a natural finish; lower barrel is phenolic with nylon plastic button (dust cap models have neoprene buttons)
Optional Lockout
Stainless steel selector switch lockout, locks two or three position handle in any position. Securing rod for push button units. See catalog pages for details
Nameplate Mounting Bracket
Make circuit description/identification easy and eliminate costly field installation (drilling/tapping) to accommodate circuit identification nameplates by using our bracket accessory. See catalog.
Modified Operation Three Position Selector Switches
Momentary contact right position, spring return to center, maintained contact left position. Momentary contact left position, spring return to center, maintained contact right position. Alternate contacts available. See catalog pages for details
Pilot Light Options
Pilot light jewel/guard assembly is available in amber, blue, clear, green and opal. LED jewel/guard assembly is available in red, amber and green. See catalog pages for details
SPLS Standard Materials and Finishes
Pilot light guard and body assembly is copperfree (4/10 of 1% max.) aluminum with a natural finish; steel clamping ring; and tempered glass jewel
Compatible with Series
N1, N2
Language
English
Background Color
Black
Legend Color
White
Keyway Type
No Keyway

Description

Legend Plate, Half-Round, Legend Test, For Use With EFD and EFDB Control Stations, Legend/Background Color White/Black, Material Aluminum
