Shop All Solenoid Air Control Valves
Aro

Solenoid Air Control Valve, 1/4 In, 24VDC

original price: $268.33
11% off
new price: $237.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Valve Ways and Positions 4-Way/2-Position
  • Voltage 24V DC
  • Valve Actuator / Return Solenoid / Solenoid
  • Coefficient of Volume 0.7
  • Pipe Size 1/4 in
See all product information

Product Information

Dimensions

Pipe Size 1/4 in
Overall Length 6 11/16 in
Overall Width 1 1/32 in
Overall Height 1 3/8 in

Details

Item Solenoid Air Control Valve
Valve Ways and Positions 4-Way/2-Position
Voltage 24V DC
Valve Actuator / Return Solenoid / Solenoid
Coefficient of Volume 0.7
Max. CFM - Valves 26 cfm
Operational Pressure Range 45 to 115 psi
NEMA Classification NEMA 4
Actuator/Return Solenoid/Solenoid
Shifting Technology Solenoid/Pilot
Air Valve Type 4-Way, 2-Position
CFM 26
Body Style Body Ported
Pressure Range 45 to 115 psi
Electrical Connections DIN Connectors
Power Consumption 4.8 W
Ambient Temp. Range 15 Degrees to 122 Degrees F

Description

Solenoid Air Control Valve, Valve Ways and Positions 4-Way/2-Position, Voltage 24V DC, Valve Actuator / Return Solenoid / Solenoid, Pipe Size 1/4 in, Max. CFM - Valves 26 cfm, Operational Pressure Range 45 to 115 psi, NEMA Classification NEMA 4, Body Style Body Ported, Coefficient of Volume 0.7, DIN Connectors Electrical Connections, Shifting Technology Solenoid/Pilot, Power Consumption 4.8 W, Ambient Temp. Range 15 Degrees to 122 Degrees F, Overall Height 1 3/8 in, Overall Length 6 11/16 in
