Shop All Solenoid Air Control Valves
Aro
Solenoid Air Control Valve, 1/8 In, 24VDC
Mfr # A211SS-024-D
Zoro # G3245724
product price: $162.99
/ea
Free Shipping & Returns
$162.99
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Valve Ways and Positions 4-Way/2-Position
- Voltage 24V DC
- Valve Actuator / Return Solenoid / Spring
- Coefficient of Volume 0.9
- Pipe Size 1/8 in
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
Product Information
- Brand Aro
- MFR # A211SS-024-D
- Zoro # G3245724
- Country of Origin United States
- Category Solenoid Air Control Valves
Dimensions
| Pipe Size | 1/8 in |
| Overall Width | 1 15/16 in |
| Overall Height | 3 1/4 in |
| Overall Length | 3 1/2 in |
Details
| Item | Solenoid Air Control Valve |
| Valve Ways and Positions | 4-Way/2-Position |
| Voltage | 24V DC |
| Valve Actuator / Return | Solenoid / Spring |
| Coefficient of Volume | 0.9 |
| Max. CFM - Valves | 30 cfm |
| Operational Pressure Range | 50 to 150 psi |
| NEMA Classification | NEMA 4 |
| Actuator/Return | Solenoid/Spring |
| CFM | 30 |
| Shifting Technology | Solenoid/Pilot |
| Body Style | Body Ported |
| Air Valve Type | 4-Way, 2-Position |
| Ambient Temp. Range | 0 Degrees to 180 Degrees F |
| Vacuum Range | 29" Hg |
| Power Consumption | 4.8 W |
| Electrical Connections | DIN Connectors |
| Pressure Range | 50 to 150 psi |
| Valve Vacuum Range | 0 to 29 in Hg |
Description
Solenoid Air Control Valve, Valve Ways and Positions 4-Way/2-Position, Voltage 24V DC, Valve Actuator / Return Solenoid / Spring, Pipe Size 1/8 in, Max. CFM - Valves 30 cfm, Operational Pressure Range 50 to 150 psi, NEMA Classification NEMA 4, Valve Vacuum Range 0 to 29 in Hg, Body Style Body Ported, Coefficient of Volume 0.9, DIN Connectors Electrical Connections, Shifting Technology Solenoid/Pilot, Power Consumption 4.8 W, Ambient Temp. Range 0 Degrees to 180 Degrees F, Overall Height 3 1/4 in
