Shop ARO

Solenoid Air Control Valve, 1/8NPT, 12VDC

  • Mfr # M813SD-012-D

  • Zoro # G1915751

product price:  $210.99
/ea
Free Shipping & Returns

Key Features

Body Style
Body-Ported
Series
Sierra
Voltage
12V DC
Valve Actuator / Return
Solenoid / Solenoid
Power Consumption
1.9 W
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
M813SD-012-D
Zoro #
G1915751
UPC #
-
Country of Origin
Japan

Dimensions

Overall Height
1 in
Overall Width
1 in
Overall Length
6 11/32 in
Pipe Size
1/8 in
Exhaust Port Connection Size
1/4 in
Pilot Port Connection Size
M5
Inlet Port Connection Size
1/8 in

Details

Item
Solenoid Air Control Valve
Body Style
Body-Ported
Series
Sierra
Voltage
12V DC
Valve Actuator / Return
Solenoid / Solenoid
Power Consumption
1.9 W
Coefficient of Volume
0.5
Center Position
Closed
Body Material
Aluminum
Override
Non-Locking
Actuator/Return
Solenoid/Solenoid
Electrical Connections
DIN Connectors
Valve Ways and Positions
4-Way/3-Position
Shifting Technology
Solenoid/Pilot
Air Valve Type
4-Way, 3-Position
NEMA Classification
NEMA 4
CFM
21
Ambient Temp. Range
0 Degrees to 122 Degrees F
Max. CFM - Valves
21 cfm
Operational Pressure Range
0 to 115 psi
Pressure Range
0 to 115 psi
Number of Positions
Three-Position
Number of Ways
Four-Way
Product Type
Solenoid Air Control Valve
Pilot Port Connection Type
NPT
Includes Mounting Hardware
Hardware Not Included
Number of Ports
5
Valve Action
Normally Closed
Electrical Connection Type
DIN Solenoid Connector
Actuator Type
Double Solenoid
Operating Pressure - Maximum
115 psi
Operating Temperature - Maximum
122 Degrees F
Pilot Type
Internal Pilot
Inlet Port Connection Gender
Female
Response Time
22 msec
Exhaust Port Connection Type
NPT
Valve Type
Spool
Includes Solenoid Coil
Solenoid Coil Included
Fail Position
Closed
Return Action
Solenoid Return
Vacuum Rating
Not Vacuum Operable
Inlet Port Connection Type
NPT
NEMA Rating
4
For Media
Air
Pilot Port Connection Gender
Female
Operating Temperature - Minimum
0 Degrees F
Body Features
Single
Exhaust Port Connection Gender
Female
Flow Rate - Maximum
21 cfm
Spool Material
Aluminum
Operating Pressure - Minimum
22 psi
Coefficient of Volume (Cv)
0.5

Description

Solenoid Air Control Valve, Valve Ways and Positions 4-Way/3-Position, Voltage 12V DC, Center Position Closed, Valve Actuator / Return Solenoid / Solenoid, ISO Class Not Applicable, Pipe Size 1/8 in, Max. CFM - Valves 21 cfm, Operational Pressure Range 0 to 115 psi, NEMA Classification NEMA 4, Body Style Body-Ported, Pilot Pressure Not Applicable, Coefficient of Volume 0.5, DIN Connectors Electrical Connections, Shifting Technology Solenoid/Pilot, Power Consumption 1.9 W
