Explosion Proof Transducer, 0 to 60 psi

  • Zoro #: G0122534
  • Mfr #: A2XBF0415C260#G

$514.48

  • Wetted Materials - Transmitters: 316 Stainless Steel
  • Features: -
  • Thermal Error: +/-2% (-4 Degrees to 185 Degrees F)
See full product details
  • This item ships free.
  • Shipping & Returns
  • Sign up for Zmail and get 15% off your first order

Ashcroft #A2XBF0415C260#G Specifications

  • Zoro #: G0122534
  • Mfr #: A2XBF0415C260#G
Wetted Materials - Transmitters: 316 Stainless Steel Features: -
Thermal Error: +/-2% (-4 Degrees to 185 Degrees F) Includes: Instructions
Safety Rating: Class 1, Div. 1 & 2 , Groups A, B, C, and D, Class 2, Div. 1 & 2 , Groups E, F, and G Safety Rating - Transmitter: Class I, Div. 1 and 2, Groups A, B, C, D; Class II, Div. 1 and 2 , Groups E, F, G
Process Connection Size - Transmitter: 1/2" Electrical Connections: 1/2" NPT Male Conduit
Electrical Connections - Transmitter: 3 ft. Cable Manufacturers Warranty Length: 1 yr.
Range Values - Transmitter: 0 to 60 Output: 1 to 5VDC
Accuracy - Transmitter: +/-0.25% Range: 0 to 60 psi
Transmitter Type: Explosion Proof Pressure Transmitter Power Required - Transmitters: 10 to 36VDC
Wetted Materials: 316 Stainless Steel Output - Transmitter: 1 to 5VDC
Process Connection Type - Transmitter: FNPT Range Units - Transmitter: psi
Wiring Entry - Transmitter: 1/2" FNPT Operating Temp. - Transmitter: -40 Degrees to 257 Degrees F
Lead Length (In.): 36 Calibration Certificate: -
NEMA Rating: 7 and 9 Operating Temp.: -40 to 257 F
Loop Resistance: - Max. Pressure (PSI): 120
For Use With: - Housing: 304 Stainless Steel
Compatible With: Any Process Compatible with 316Stainless Steel Process Connection: 1/2" NPT Female
Power Required: 10 to 36VDC Accuracy: +/-0.3%
Item: Explosion Proof Pressure Transmitter Country of Origin (subject to change): United States
Feedback Help us improve our product information

Description

Explosion Proof Pressure Transmitter, Wetted Materials - Transmitters 316 Stainless Steel, Range Values - Transmitter 0 to 60, Range Units - Transmitter psi, Accuracy - Transmitter +/-0.25 Percent, Electrical Connections - Transmitter 3 ft. Cable, Power Required - Transmitters 10 to 36VDC, Process Connection Size - Transmitter 1/2 In., Process Connection Type - Transmitter FNPT, Output - Transmitter 1 to 5VDC, Operating Temp. - Transmitter -40 Degrees to 257 Degrees F
