  9. Gauge, Vacuum, 30in Hg VAC to 0, ABS
Ashcroft Gauge, Vacuum, 30in Hg VAC to 0, ABS 25W1005PH02LVAC - main

Gauge, Vacuum, 30in Hg VAC to 0, ABS

  • Mfr # 25W1005PH02LVAC

  • Zoro # G8515963

product price: $15.65
/ea

Key Features

Pressure and Vacuum Gauge Type
Vacuum Gauge
Gauge Application
General-Purpose Case
Liquid Filled
No
Gauge Nominal Dial Size
2 1/2 in
Basic Gauge Case Material
Plastic
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
25W1005PH02LVAC
Zoro #
G8515963
UPC #
-
Country of Origin
Brazil

Dimensions

Gauge Nominal Dial Size
2 1/2 in
Gauge Connection Size
1/4 in
Manufacturers Warranty Length
1 yr
Connection Size
1/4 in NPT
Nominal Dial Size
2 1/2 in
Case Depth
1.12 in
Process Connection Size
1/4 in
Manufacturer Warranty Length
1 yr
Case Diameter
2.74 in
Nominal Dial Diameter
2 1/2 in

Details

Pressure and Vacuum Gauge Type
Vacuum Gauge
Gauge Application
General-Purpose Case
Liquid Filled
No
Basic Gauge Case Material
Plastic
Basic Gauge Wetted Parts
Brass / Bronze
Gauge Connection Type
MNPT
Gauge Connection Location
Bottom
Gauge Primary Range Units
in Hg
Operating Temp. Range
-40 Degrees to 150 Degrees F
Case Color
Black
Basic Gauge Socket Material
Brass
Basic Gauge Sensor Material
Bronze
Range
30 in Hg Vac to 0
Gauge Socket Material
Brass
Gauge Panel Mountable
No
Calibration Certificate Included
No
Gauge Primary Range Smallest Graduation
0.5
Graduations
1 in Hg
Connection Location
Lower
Gauge Accuracy
+/-3-2-3%
Series
1005P
Gauge Lens Material
Polycarbonate
Gauge Special Options
PowerFlex(TM) Movement
Gauge Case Material
ABS
Item
Industrial Vacuum Gauge
Basic Gauge Lens Material
Plastic
Gauge Case Color
Black
Gauge Sensor Material
Bronze
Smallest Graduation
0.5 in Hg
Gauge Primary Range Values
-30 to 0
Gauge Primary Range Numbered Graduations
1
Gauge Case Liquid
None
Process Connection Location
Bottom
Standards
ASME, CRN, UL 252A
Pointer Material
Aluminum
Primary Pressure Range
30 to 0
Movement Material
Polyester
Field Fillable
No
Hazardous Location Rating
Not Rated
Primary Pressure Scale Color
Black
Application
Beverage Dispensing Systems, Filtration Monitoring, Hydraulics, Instrument and Controls, OEM Applications, Paint Sprayers, Pneumatics, Pumps, Water Pressure Testing
Dry Dampening Feature
FlutterGuard
Non-Sparking
No
Pointer Color
Black
Dial Face Material
Aluminum
Scale Type
Single
Accuracy Grade
ASME B40.100 Grade B
Primary Scale Units
in Hg
Pressure Range Type
Vacuum
Socket Material
Brass
Accuracy
+/-3-2-3%
Compatible Process Media
Water
Freeze Resistant Movement
No
Sensor Type
Bourdon Tube
Blowout Safety Back
No
Removable Bezel
No
Includes Calibration Certificate
No
Vibration Resistance
Liquid-Filled
Panel-Mountable
No
Process Connection Type
NPT
Sensor Material
Bronze
Includes Vent Plug
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Includes Mounting Hardware
No
Dial Color
White
Cleaned for Oxygen Service
No
Primary Scale Minor Graduations
0.5
Lens Material
Polycarbonate
Liquid-Filled Case
No
IP/NEMA Rating
Not Rated
Accuracy Scale
Mid-Scale
Process Temperature Range
-40 Degrees to 150 Degrees F
Primary Scale Numeric Increments
1
Pressure Gauge Type
Industrial Pressure Gauge
Process Connection Gender
Male
Case Material
ABS
Operating Temperature - Maximum
150 Degrees F
Process Media Temperature - Maximum
150 Degrees F
Process Media Temperature - Minimum
-40 Degrees F
Case Liquid
None
Primary Scale Color
Black
Primary Scale Vacuum Measurement - Minimum
30 in Hg
Primary Scale Vacuum Measurement - Maximum
0 in Hg
Compatible with Brand
Universal
Operating Temperature - Minimum
-40 Degrees F

Description

Industrial Vacuum Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material ABS, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating Not Rated, Primary Pressure Range 30 to 0, Dry Dampening Feature FlutterGuard, Dial Color White, Pressure Gauge Type Industrial Pressure Gauge, Liquid-Filled Case No
