Solenoid Air Con Valve, Five-Way, 145 psi

  • Mfr # R422103555

  • Zoro # G116664421

product price:
$
160.99
/ea
Free Shipping & Returns

Key Features

Series
LS04-XS
Number of Positions
Two-Position
Flow Rate - Maximum
200 lpm
Voltage
24V DC
Overall Height
50 mm
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
R422103555
Zoro #
G116664421
UPC #
-
Country of Origin
France

Dimensions

Overall Height
50 mm
Inlet Port Connection Size
4 mm
Overall Length
54 13/16 mm
Exhaust Port Connection Size
4mm
Overall Width
10 13/16 mm
Wire Rope Length
54 13/16 mm
Length
54 13/16 mm

Details

Item
Directional Control Valve
Series
LS04-XS
Number of Positions
Two-Position
Flow Rate - Maximum
200 lpm
Voltage
24V DC
Application
Industrial
Coefficient of Volume (Cv)
0.4
For Media
Compressed Air
Seal Material
Polyurethane
Operating Pressure - Maximum
7 bar
Valve Type
Spool
Vacuum Rating
Not Vacuum Operable
Actuator Type
Single Solenoid
Return Action
Spring Return
Includes Solenoid Coil
Solenoid Coil Included
Duty Cycle
Continuous
Number of Ways
Four-Way
Override
Non-Locking
Inlet Port Connection Gender
Female
Body Style
Body-Ported
Product Type
Solenoid Air Control Valve
Power Consumption
0.8 W
Standards
DIN EN 61140 Class III, Generic Emission Standard in Accordance EN 61000-6-4:2002, Generic Immunity Standard in Accordance IEC 61000-6-2:2005
Pilot Pressure
3 bar
Number of Ports
5
Body Material
Aluminum
Exhaust Port Connection Type
Push-On
Response Time
9 msec
Pilot Type
Internal Pilot
Electrical Connection Type
Plug-In
Pilot Port Connection Gender
Female
Body Features
Single
Operating Temperature - Minimum
-10 Degrees C
Operating Pressure - Minimum
3 bar
Operating Temperature - Maximum
50 Degrees C

Description

Directional Control Valve, Voltage 24V DC, Center Position Not Applicable, ISO Class Not Applicable, Body Style Body-Ported, Pilot Pressure 3 bar, Power Consumption 0.8 W, Override Non-Locking, Overall Height 50 mm, Overall Length 54 13/16 mm, Overall Width 10 13/16 mm, Standards DIN EN 61140 Class III, Generic Emission Standard in Accordance EN 61000-6-4:2002, Generic Immunity Standard in Accordance IEC 61000-6-2:2005
