  6. Three-Phase General Purpose Motor, 2 HP, 56 Frame, 208-230/460V AC Voltage, 1755 rpm Nameplate RPM
Baldor-Reliance Three-Phase General Purpose Motor, 2 HP, 56 Frame, 208-230/460V AC Voltage, 1755 rpm Nameplate RPM EM3558 - main

Three-Phase General Purpose Motor, 2 HP, 56 Frame, 208-230/460V AC Voltage, 1755 rpm Nameplate RPM

  • Mfr # EM3558

  • Zoro # G8238185

product price:  $916.99
/ea
Free Shipping & Returns

Key Features

HP
2
Nameplate RPM
1755 rpm
Voltage
208-230/460V AC
Motor Mounting Type
Rigid Base
Full Load Amps
5.8/2.9 A
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
EM3558
Zoro #
G8238185
UPC #
781568295960
Country of Origin
United States

Dimensions

Length Less Shaft
11 3/8 in
Overall Length
13 1/4 in
Shaft Dia.
5/8 in
Shaft Length
1 7/8 in
Manufacturers Warranty Length
3 yr

Details

Item
General Purpose Motor
HP
2
Nameplate RPM
1755 rpm
Voltage
208-230/460V AC
Motor Mounting Type
Rigid Base
Full Load Amps
5.8/2.9 A
Frame
56
Motor Bearings
Ball
Motor Service Factor
1.15
Motor Design
Three-Phase
Motor Enclosure Design
Totally Enclosed Fan Cooled
RPM Range
1701-1800
Phase
Three
No. of Speeds
1
Motor Application
General Purpose
Motor Shaft Rotation
CW/CCW
Voltage Compatibility
200-230/460V AC, 208-230/460V AC, 460V AC
Hz
60 Hz
Ins. Class
F
Max. Ambient Temp.
40 Degrees C
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Shaft Design
Keyed
Nominal Efficiency
86.5 %
Standards
CSA, CSA EEV, UR
CC Number
CC031A
Inverter Rated
Yes
Motor Thermal Protection
None
Green Certification or Other Recognition
NEMA Premium(R) Rated
NEMA Design
B
Duty Cycle
Continuous
Usable @ 208V
Yes
Usable @ 200V
No
Weight
44 lb

Description

Here is the revised description:

The BALDOR-RELIANCE - EM3558 is a General Purpose Motor, which falls under the category of 3-Phase AC Motors. This motor is widely used in industrial and commercial settings for power transmission and pneumatics applications. It converts electrical energy into mechanical energy to operate various types of machinery, making it versatile across different sectors such as manufacturing lines and HVAC systems.

Key Features of the BALDOR-RELIANCE - EM3558 General Purpose Motor:

  • CC Number: The unique identifier assigned by EASA classifies this motor based on its design, specifications, and performance characteristics.
  • Duty Cycle: Its continuous duty cycle is designed for continuous operation in industrial applications.
  • Frame: With a frame size of 56, it conforms to standard specifications for compatibility and interchangeability.
  • Full Load Amps: Draws a maximum current of 5.8/2.9 A when operating at full capacity compatible with specified current limits.
  • NEMA Premium(R) Rated: Rated as per NEMA Premium(R) standards
  • Inverter Rated: Compatible with variable frequency drives, which may allow control over speed and torque
  • Motor Enclosure Design: Totally enclosed fan-cooled design is designed to help protect internal components from environmental factors and aid in cooling
