  9. 1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 KEYCONNECT, BLACK
Belden 1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 KEYCONNECT, BLACK AX101321 - main

1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 KEYCONNECT, BLACK

  • Mfr # AX101321

  • Zoro # G0168568

product price: $12.99
/ea

Key Features

Color
Black
Number of Ports
1
Max. Contact Resistance
20 m-Ohm
Footprint/Type
KeyConnect
Mated Connection Table - Footnote
TIA/EIA-568-C.2-1-2002 Category 6 Standard.
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AX101321
Zoro #
G0168568
UPC #
-
Country of Origin
Unknown

Dimensions

Depth (in.)
1.29
Height (in.)
0.88
Width (in.)
0.64

Details

Color
Black
Number of Ports
1
Max. Contact Resistance
20 m-Ohm
Footprint/Type
KeyConnect
Mated Connection Table - Footnote
TIA/EIA-568-C.2-1-2002 Category 6 Standard.
Installation Temperature Range
-10°C To +60°C
Termination Resistance
2.5 m-Ohm
Current Rating
1.500 A
Plug/Connector Retention
11.250 lbs.
Insulation Resistance
500 M-Ohm Minimum
Plug / Jack Compatibility
RJ45, RJ11
Third Party Performance Verification
ETL - Verified Category 6
Suitability - Indoor
Yes - Indoor
Operating Temperature Range
-10°C To +60°C
Tool Compatibility
Belden 110 Connecting Tool, MediaFlex Termination Station
Connector/Hardware Retention
20 lbs.
Item Desc
CAT6+ JACK KCONN BLACK
Safety Listing
ACA, Bi-national Standard Listed
Dielectric Strength
1,000 V RMS @ 60 Hz for 1 minute
Included Parts
1 T-Bar
Telecommunications Standards
Category 6 - TIA 568.B.2-1, ISO/IEC 11801:2002 Ed.2
Wiring Scheme
T568A/B
Notes (Cont'd.)
IDC Wire Gauge: 22~24 AWG
Putup
1 EA
Storage Temperature Range
-40°C To +70°C
Related Parts
Compatible with KeyConnect Faceplates, Adapters, Boxes and Patch Panels
Suitable Applications
IBDN System 2400, 3600 and 4800, TIA Category 6+, ISO Class E, 1000 BASE-T
Other Standards
FCC Part 68, Subpart F, IEC 60603-7
Product Color
Black
Connector Details
1 x RJ-45 Network Female
Product Line
GigaFlex
Product Material
Plastic, Copper
Product Name
GigaFlex AX101321 Cat.6 Keystone Jack
Product Type
Network Connector
Certifications & Standards
T568A/B, UL 94V-0, FCC part 68, IEC-603-7
Wiring
A/B Universal
Category
CATEGORY 6
Termination
Idc
