  5. 1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 KEYCONNECT, DARK BLUE
Belden 1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 KEYCONNECT, DARK BLUE AX104193 - main

1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 KEYCONNECT, DARK BLUE

  • Mfr # AX104193

  • Zoro # G0521413

product price:  $12.99
/ea
Sold in multiples of 10 for $129.90

Key Features

Color
Blue
Height
0.9"
Width
0.6"
Depth
1.3"
Number of Ports
1
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
AX104193
Zoro #
G0521413
UPC #
-
Country of Origin
Unknown

Dimensions

Height
0.9"
Width
0.6"
Depth
1.3"
Depth (in.)
1.29
Width (in.)
0.64
Height (in.)
0.88

Details

Color
Blue
Number of Ports
1
Installation Temperature Range
-10°C To +60°C
Plug/Connector Retention
11.250 lbs.
Suitable Applications
IBDN System 2400, 3600 and 4800, TIA Category 6+, ISO Class E, 1000 BASE-T
Tool Compatibility
Belden 110 Connecting Tool, MediaFlex Termination Station
Insulation Resistance
500 M-Ohm Minimum
Termination Resistance
2.5 m-Ohm
Storage Temperature Range
-40°C To +70°C
Telecommunications Standards
Category 6 - TIA 568.C.2, ISO/IEC 11801:2002 Ed.2
Included Parts
1 T-Bar
Safety Listing
ACA, Bi-national Standard Listed
Max. Contact Resistance
20 m-Ohm
Connector/Hardware Retention
20 lbs.
Related Parts
Compatible with KeyConnect Faceplates, Adapters, Boxes and Patch Panels
Suitability - Indoor
Yes - Indoor
Current Rating
1.500 A
Other Standards
FCC Part 68, Subpart F, IEC 60603-7
Wiring Scheme
T568A/B
Other Specification
UL 1963
Footprint/Type
KeyConnect
Dielectric Strength
1,000 V RMS @ 60 Hz for 1 minute
Mated Connection Table - Footnote
TIA/EIA-568-C.2 Category 6 Standard.
Third Party Performance Verification
ETL - Verified Category 6
Item Desc
CAT6+ JACK KCONN BLUE (DARK)
Operating Temperature Range
-10°C To +60°C
Notes (Cont'd.)
IDC Wire Gauge: 22~24 AWG
Putup
1 EA
Plug / Jack Compatibility
RJ45, RJ11
Product Name
CAT6+ Modular Jack, RJ45, KeyConnect Style
Package Contents
CAT6+ Modular Jack, RJ45, KeyConnect Style, 1 x T-Bar
Compatibility
Belden: IBDN System 2400, IBDN System 3600, IBDN System 4800, 110 Connecting Tool, MediaFlex Termination Station
Contact Material
Copper Alloy
Product Type
Network Connector
Connector Details
1 x RJ-45 Network Female
Product Line
KeyConnect
Product Material
Plastic
Product Color
Blue
Wiring
A/B Universal
Termination
Idc
Category
CATEGORY 6
