  5. 1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 MDVO-STYLE, PS6+ BLACK
Belden 1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 MDVO-STYLE, PS6+ BLACK AX101066 - main

1-PORT MOD JACK 8W8P UTP, T568A/B CAT6 IP5 MDVO-STYLE, PS6+ BLACK

  • Mfr # AX101066

  • Zoro # G0185858

product price:  $16.19
/ea

Key Features

Color
Black
Number of Ports
1
Width (in.)
0.77
Suitable Applications
IBDN System 2400 and 4800, TIA Category 6+, ISO Class E, 1000 BASE-T
Depth (in.)
1.29
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
AX101066
Zoro #
G0185858
UPC #
611589002325
Country of Origin
Unknown

Dimensions

Width (in.)
0.77
Depth (in.)
1.29
Height (in.)
0.765

Details

Color
Black
Number of Ports
1
Suitable Applications
IBDN System 2400 and 4800, TIA Category 6+, ISO Class E, 1000 BASE-T
Plug / Jack Compatibility
RJ45, RJ11
Related Parts
Compatible with Interface and MDVO Style Faceplates, Adapters, Boxes and Patch Panels
Connector/Hardware Retention
20 lbs.
Putup
1 EA
Telecommunications Standards
Category 6 - TIA 568.B.2-1, ISO/IEC 11801:2002 Ed.2
Dielectric Strength
1,000 V RMS @ 60 Hz for 1 minute
Included Parts
1 T-Bar +1 Dust Cap
Other Standards
FCC Part 68, Subpart F, IEC 60603-7
Storage Temperature Range
-40°C To +70°C
Tool Compatibility
Belden 110 Connecting Tool, MediaFlex Termination Station
Notes (Cont'd.)
IDC Wire Gauge: 22~24 AWG
Termination Resistance
2.5 m-Ohm
Suitability - Indoor
Yes - Indoor
Wiring Scheme
T568A/B
Insulation Resistance
500 M-Ohm Minimum
Installation Temperature Range
-10°C To +60°C
Plug/Connector Retention
11.250 lbs.
Mated Connection Table - Footnote
TIA/EIA-568-C.2 Category 6 Standard.
Footprint/Type
MDVO-Style
Max. Contact Resistance
20 m-Ohm
Safety Listing
ACA, Bi-national Standard Listed
Operating Temperature Range
-10°C To +60°C
Item Desc
CAT6+ JACK MDVO BLACK
Third Party Performance Verification
ETL - Verified Category 6
Current Rating
1.500 A
Wiring
A/B Universal
Category
CATEGORY 6
Termination
Idc
Sub Family
PS6+ JACK
Family
GIGAFLEX

Description
