  11. AC Gearmotor, 204 in.-lb. Max. Torque, 14 Nameplate RPM, 115VAC Voltage, 1 Phase

This item is Discontinued.

Bison Gear & Engineering AC Gearmotor, 204 in.-lb. Max. Torque, 14 Nameplate RPM, 115VAC Voltage, 1 Phase 016-562-0121

AC Gearmotor, 204 in.-lb. Max. Torque, 14 Nameplate RPM, 115VAC Voltage, 1 Phase (Discontinued)

  • Mfr # 016-562-0121
  • Zoro # G6859097
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
016-562-0121
Zoro #
G6859097
UPC #
845171002886
Country of Origin
United States

Dimensions

Length Less Shaft
6 59/64 in
Keyway Size Type
3/16 in Square x 1 1/8 in
Overall Length
17 in
Keyway Size
3/16" Square x 1-1/8"
Shaft Dia. (Dimension U)
3/4 in

Details

Item
AC Gearmotor
Gearmotor Voltage
115V AC
Gearmotor Phase
1
Gearmotor Type
AC Gearmotor
Max. Torque
204 in-lb
Gearmotor Shaft Type
Hollow
Gearmotor Shaft Orientation
Parallel
Nameplate RPM
14
Gearmotor Enclosure
Totally Enclosed Nonventilated
Gearmotor Mounting Position
All Angle
Full Load Amps
0.60
Input HP
1/20
Mounting
All Position
RPM Range
0 to 15
Seals
Lip
Insulation Class
F
Voltage
115
Shaft Orientation
Parallel
Thermal Protection
None
Reversible Shaft Output
Yes
Phase
1
Enclosure
TENV
Gear Material
Steel
Finish
Unpainted
Bearings
Ball, Gearing Needle
Gear Type
Helical
Motor Type
PSC
Lubrication
Grease Filled
Gear Ratio
121:1
Capacitor Required
Included
Gear Case Material
Die Cast Aluminum
Hz
60
Number of Brake Discs Required
0
Gears
AGMA Class 9
Shaft
Hollow Output
Brake
Optional

Description

AC Gearmotor, Motor Type PSC, Gear Ratio 121:1, Shaft Orientation Parallel
