Blickle Swivel Plate Caster, TPR, 8", 660 lb. LE-ALEV 200K-14 - main

Swivel Plate Caster, TPR, 8", 660 lb.

  • Mfr # LE-ALEV 200K-14

  • Zoro # G0892390

product price:  $80.85
/ea
Free Shipping & Returns

Key Features

Number of Wheels
1
Wheel Dia.
8in
Caster Stem Type
No Stem/Plate Included
Overall Height
9-1/4in
Caster Brake Included
No
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
LE-ALEV 200K-14
Zoro #
G0892390
UPC #
-
Country of Origin
Germany

Dimensions

Wheel Dia.
8in
Overall Height
9-1/4in
Wheel Width
2in
Stem Dia.
No Stem
Mounting Bolt Dia.
3/8 in
Swivel Radius
6-1/8 in
Mounting Plate Thickness
0.138 in
Mounting Plate Size
4 in x 4-1/2 in

Details

Number of Wheels
1
Caster Stem Type
No Stem/Plate Included
Caster Brake Included
No
Item
Swivel Caster
Caster Sub-Type
Swivel
Load Rating
660 lb.
Replacement Wheel
Mfr. No. ALEV 200/20K
Tread Color
Black
Core Color
Silver
Inside Bolt Hole Spacing
3 in x 3 in
Caster Mounting Type
Plate
Frame Finish
Zinc Plated
Tread
Standard
Caster Brake Type
No Brake Included
System of Measurement
Inch
Outside Bolt Hole Spacing
2-5/8 in x 3-5/8 in
Standards
RoHS, ICWM
Non-Marking
No
Application
Retail, Industrial, Commercial
Caster Frame Material
Steel
Extended Lead
No
Swivel Raceway Type
Double Ball
Resistant To
High Chemical Resistance To Many Aggressive Substances, Except Oils
Load Rating Range
Heavy-Duty
Series
LE Series
Accessories
Optional: RI-04.14 (Directional Lock)
Load Capacity
660 lb
Tread Shape
Standard
ESD Conductive
No
Number of Mounting Holes
4
Wheel Core Material
Aluminum
Includes Thread Guards
No
Wheel Hardness Rating
65 Shore A
Wheel/Tread Material
Aluminum/Solid Rubber
Wheel Bearing Type
Precision Ball
Operating Temperature Range
-15 Degrees To 175 Degrees F

Description

Swivel
