Brad Harrison

Cordset, 4 Pin, Receptacle, Female

product price: $31.19
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Cable Length 2 m
  • Jacket Color Yellow
  • End 1 Number of Pins 4
  • End 1 Thread M12
  • Wire Size 22 AWG
See all product information

Product Information

Dimensions

Cable Length 2 m
Wire Size 22 AWG

Details

Item Cordset
Jacket Color Yellow
End 1 Number of Pins 4
End 1 Thread M12
End 1 Connection Type M12
End 2 Connection Type Bare Wire
NEMA Rating 6P
Jacket Material PVC
IP Rating IP67, IP68
Features Patented Antivibration Feature to Prevent Loosening Under High Vibration Applications
Standards CSA Certified, IEC, UL Listed
End 1 Keyway Single
Max. Amps 4 A
End 1 Gender and Plug End Female Right Angle
Number of Conductors 4
End 2 Gender and Plug End Bare Wire
End 1 Number of Keyways 1
Number of Wires 4
Cable Jacket Material PVC
End 1 Mounting Orientation Right Angle
Cordset Configuration M12 Female Right Angle X Bare Wire
End 1 Gender Female
Cordset Type Single-Ended
Connector Type M12
Cable Jacket Color Yellow

Description

Cordset, End 1 Gender Female, End 1 Thread M12, End 1 Number of Pins 4, End 1 Mounting Orientation Right Angle, End 1 Connection Type M12, End 2 Gender Not Applicable, End 2 Thread Not Applicable, End 2 Connection Type Bare Wire, Cable Length 2 m, Cable Jacket Color Yellow, Cable Jacket Material PVC, Max. Amps 4 A, Wire Size 22 AWG, IP Rating IP67, IP68, Standards CSA Certified, IEC, UL Listed, NEMA Rating 6P, End 1 Number of Keyways 1
