  11. Locking Receptacle, L8-30R, 30 A, 480V AC, 2 Pole, Flush Mount, Screw Terminals, White
Bryant Locking Receptacle, L8-30R, 30 A, 480V AC, 2 Pole, Flush Mount, Screw Terminals, White 70830FR - main

Locking Receptacle, L8-30R, 30 A, 480V AC, 2 Pole, Flush Mount, Screw Terminals, White

  • Mfr # 70830FR

  • Zoro # G204391994

product price: $52.26
/ea

Key Features

NEMA Receptacle Configuration
L8-30R
Current Rating
30 A
Voltage Rating
480V AC
Number of Poles
2
Number of Wires
3
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
70830FR
Zoro #
G204391994
UPC #
781786691131
Country of Origin
Puerto Rico

Dimensions

Wire Size
#14 AWG to #8 AWG
Height
1.24 in
Width
1.70 in
Length
3.28 in

Details

Item
Locking Receptacle
NEMA Receptacle Configuration
L8-30R
Current Rating
30 A
Voltage Rating
480V AC
Number of Poles
2
Number of Wires
3
Wire Connection Type
Screw Terminals
Grounding
Grounded
Housing Color
White
Mount Type
Flush
Cover Type
No Cover
Standards
Certified for current interrupting at full rated current, FED SPEC UL/CSA
Flange Type
Non-Flanged
Mounting Type
Screw Mounting
Material
Composite
Wiring Style
Single Receptacle
Application
Extra Heavy Duty Industrial
Features
Combination back and side wiring terminals accept #14 through #8 AWG solid or stranded conductors; Heavy duty mounting straps are nickel-plated to resist corrosion, wide width design assures secure assembly; NEMA rating and configuration are molded into face for easy identification; One-piece, rivetless copper-alloy contact design reduces heat buildup and provides secure blade retention
Temperature Rating
Maximum Continuous: 75° C; Minimum Continuous: -40° C w/o impact
Insulation
Insulated Body
Style
Single Receptacle
Material - Mounting Hardware
Screw Mounting
Amperage Rating
30 A
Dielectric Strength
Withstands 3000V Minimum in
Resistance Properties
nickel-plated to resist corrosion

Description

Locking Devices, Industrial, Flush Receptacle, 30A 480V AC, 2-Pole 3-Wire Grounding, L8-30R, Screw Terminal, White
