  11. Wall Switch, White, 3-Way Type, 1 to 2 HP
Bryant Wall Switch, White, 3-Way Type, 1 to 2 HP RSD315W - main

Wall Switch, White, 3-Way Type, 1 to 2 HP

  • Mfr # RSD315W

  • Zoro # G4818311

product price: $12.50
/ea

Key Features

Switch Type
3-Way
Switch Style
Rocker
Amps AC
15 A
Color
White
Voltage AC
120
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
RSD315W
Zoro #
G4818311
UPC #
883778101250
Country of Origin
China

Dimensions

Overall Width
1.5 in
Overall Height
1.5 in

Details

Item
Wall Switch
Switch Type
3-Way
Switch Style
Rocker
Amps AC
15 A
Color
White
Voltage AC
120
Locking
No
Switch Function
Maintained
Wiring Method
Back, Side
Application Environment
General Purpose
Description/Special Features
Thermoplastic Cover/Base
Standards
CSA Certified, UL E3896
Rated HP
1 to 2
Antimicrobial
No
Voltage Rating
120V AC
Wire Connection Type
Push In, Screw Terminals
Market
Residential
Current Rating
15 A
Number of Switches
1
Features
Smooth, Quiet Rocker, Ultrasonically Welded Cover and Base
Grounding
Grounded
Horsepower Rating
2 hp
Performance
Electrical - Dielectric voltage - Withstands 1,500V AC minimum for 1 minuteElectrical - Endurance - 30,000 cycles minimumElectrical - Max. working voltage - 120VElectrical - Overload - 1.5 times ratingEnvironmental - Flammability - UL V0Environmental - Operating temperatures - Maximum continuous 60°Cminimum -20°C (without impact)Mechanical - Terminal accommodation - Back and side wire: #14 AWG min. - #12 AWG max. solid and stranded copper wire onlypush wire: #14 AWG solid copper wire only
Industry Standard(s)
CSA CertifiedUL Listed E3896

Description

Wall Switch, Color White, Current Rating 15 A, Switch Function Maintained, Switch Type 3-Way, Voltage Rating 120V AC, Wiring Method Back, Side, Horsepower Rating 2 hp, Locking Style Not Applicable, Number of Switches 1, Standards CSA Certified, UL E3896, Switch Style Rocker, Wire Connection Type Push In, Screw Terminals, Features Smooth, Quiet Rocker, Ultrasonically Welded Cover and Base, Grounding Grounded, Market Residential, Overall Height 1.5 in
