Mechanical Lug, 250 kcmil Max, 4 Conductor, 4 Hole, 1/2 in Stud, Aluminum
Mfr # K4A29U4N
Zoro # G4663635
product price:Â $90.89
/eaKey Features
For Conductor Material
Aluminum, Copper
For Minimum Wire Size
6 AWG
For Maximum Wire Size
250 kcmil
Number of Conductors
4
Number of Terminations
4
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Product Information
- MFR #
- K4A29U4N
- Zoro #
- G4663635
- UPC #
- 781810559376
- Country of Origin
- United States
Dimensions
- For Minimum Wire Size
- 6 AWG
- For Maximum Wire Size
- 250 kcmil
- For Stud Size
- 1/2 in
- Hole Diameter
- 0.56 in
- Tongue Width
- 3.69 in
- Length
- 4.25 in
- Width
- 3.69 in
- Max. Conductor Size
- 250 kcmil Stranded
- Stud Size
- 1/2 in
- Min. Conductor Size
- 6 AWG Stranded
- Length (Straight Wireway)
- 4.25 in
- Overall Width
- 4 in
- Overall Length
- 4.25 in
- For Stranded Copper Wire Size - Maximum
- 250 kcmil
- For Stranded Copper Wire Size - Minimum
- 6 AWG
- Overall Depth
- 4 in
- Tongue Thickness
- 0.31 in
- Tongue Length
- 3.16 in
- Conductor Size
- 6 AWG-250 KCMIL
- Dimension - L Length Overall mm
- 108 mm 115 mm
- Conductor - AL Str Size
- 6 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil 6 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 AWG;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil;266 kcmil;300 kcmil;336 kcmil;350 kcmil
- Dimension - Length Overall inch
- 4.25 in 4.50 in
- Dimension - Width inch
- 3.69 in
- Conductor - Copper Str Size Range
- 6 AWG (Str)-250 kcmil 6 AWG (Str)-350 kcmil
- Dimension - Pad Width inch
- 4.00 in 4.72 in
- Dimension - Bolt Size fraction
- 1 to 2
- Dimension - N inch
- 0.63 in
- Dimension - Hole Size inch
- 0.56 in
- Dimension - Bolt Hole Size inch
- 0.56 in
- Dimension - Stud Size inch
- 1/2 in
- Dimension - Height inch
- 1.19 in 1.38 in
- Dimension - Hole Size mm
- 14 mm
- Conductor - AL Str Size Range
- 6 AWG (Str)-250 kcmil 6 AWG (Str)-350 kcmil
- Dimension - Width mm
- 94 mm 128 mm
- Dimension - F Width Center to Center inch
- 1.75 in
- Dimension - Height fraction
- 1.19 in 1.4 in
- Conductor - Copper Str Size
- 6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil 6 AWG;5 AWG;4 AWG;3 AWG;2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG;250 kcmil;300 kcmil;350 kcmil
- Dimension - Width fraction
- 3-69/100 in 5-1/25 in
- Dimension - D inch
- 3.16 in 3.00 in
- Wire Rope Length
- 4.25 in
Description
Mechanical Connector, For Conductor Material Aluminum, Copper, For Stranded Copper Wire Size - Minimum 6 AWG, For Stranded Copper Wire Size - Maximum 250 kcmil, For Stud Size 1/2 in, Head Style Hex Socket, Number of Holes 4, Hole Diameter 0.56 in, Hole Spacing 1.75 in, Body Material Aluminum, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 600 V, Number of Conductors 4, Number of Terminations 4, Tongue Length 3.16 in, Tongue Width 3.69 in, Tongue Thickness 0.31 in
