  11. Offset Adapter, 600 kcmil Max, Standard Barrel, Aluminum, Yellow
Burndy Offset Adapter, 600 kcmil Max, Standard Barrel, Aluminum, Yellow AYPO600 - main

Offset Adapter, 600 kcmil Max, Standard Barrel, Aluminum, Yellow

  • Mfr # AYPO600

  • Zoro # G4670267

product price: $71.29
/ea

Key Features

For Wire Size
600 kcmil
For Conductor Material
Aluminum, Copper
Material
Aluminum
Barrel Size
Standard
Die Code
936
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
AYPO600
Zoro #
G4670267
UPC #
781810556351
Country of Origin
United States

Dimensions

For Wire Size
600 kcmil
Barrel Size
Standard
Max. Wire Size
600 kcmil
Diameter
47/64 in
Length
4.02 in
Min. Wire Size
250 kcmil
Width
1.46 in
Length (Straight Wireway)
4.02 in
Barrel Length
1.59 in
Pin Equivalent Wire Size
400 kcmil
For Stranded Copper Wire Size - Minimum
600 kcmil
For Stranded Aluminum Wire Size - Maximum
600 kcmil
Pin Length
1.64 in
Overall Length
4.02 in
Barrel Diameter
1.46 in
Strip Length
1 3/4 in
For Stranded Copper Wire Size - Maximum
600 kcmil
Pin Diameter
0.734 in
Dimension - B Outside Diameter inch
0.73 in
Dimension - Length Overall inch
4.02 in
Dimension - P inch
1.64 in
Dimension - L Length Overall mm
102 mm
Conductor - Copper DLO Size Range
444 kcmil
Dimension - B Length inch
1.59 in
Dimension - B Length fraction
1-5/8 in
Conductor - Copper DLO Size
444 KCMIL
Conductor - Copper Str Size
600 KCMIL
Equivalent Pin Size
400 kcmil
Conductor Size
600 KCMIL
Dimension - A Outside Diameter inch
1.46 in
Conductor - AL Str Size Range
600 kcmil
Conductor - AL Str Size
600 KCMIL
Dimension - Strip Length inch
1-3/4 in
Conductor - Copper Str Compact Size
600 KCMIL
Conductor - Copper Str Size Range
600 kcmil
Minimum Wire Size
250 kcmil
Maximum Wire Size
600 kcmil
For Maximum Wire Size - Stranded
600 kcmil
For Minimum Wire Size - Solid
250 kcmil
For Maximum Wire Size - Solid
600 kcmil
Maximum Run Wire Size
600 kcmil

Description

Compression Pin Terminal, Connection Orientation Offset, Die Code 936, For Conductor Material Aluminum, Copper, For Stranded Copper Wire Size - Minimum 600 kcmil, For Stranded Copper Wire Size - Maximum 600 kcmil, Insulation Material Rubber, Maximum Voltage 35 kV, Number of Crimps 3, Pin Diameter 0.734 in, Pin Equivalent Wire Size 400 kcmil, Pin Length 1.64 in, Contact Finish Tin, Contact Material Aluminum, Barrel Diameter 1.46 in, Barrel Length 1.59 in, Color Code Yellow
