One-Hole Compression Lug, 1 AWG Max, 5/16 in Stud, Standard Barrel, Copper, Pink

  • Mfr # YA25LB

  • Zoro # G4703151

product price:
$
14.55
/ea

Key Features

For Wire Size
1 AWG
For Conductor Material
Copper
For Stud Size
5/16 in
Material
Copper
Barrel Size
Standard
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
YA25LB
Zoro #
G4703151
UPC #
781810555996
Country of Origin
United States

Dimensions

For Wire Size
1 AWG
For Stud Size
5/16 in
Barrel Size
Standard
Tongue Width
0.75 in
Width
3/4"
Length
2.02"
Barrel Length
Short
Cable Size
1 AWG
Length (Straight Wireway)
2.02 in
Conductor - Copper Flex H Size
1/0 AWG
Dimension - Length Overall inch
2.02 in
Conductor - Copper Flex M Size
1 AWG
Conductor - Copper Flex I Size
1/0 AWG
Conductor - Copper Flex K Size Range
1/0 AWG
Dimension - Outside Diameter inch
0.51 in
Conductor - Copper Flex M Size Range
1 AWG
Dimension - L Length Overall mm
51 mm
Conductor - Copper DLO Size
1/0 AWG
Dimension - Hole Size fraction
2023-05-16
Dimension - Pad Width inch
0.75 in
Conductor - Copper Flex H Size Range
1/0 AWG
Dimension - Hole Size mm
8 mm
Conductor - Copper Str Size Range
1/0 AWG
Conductor - Copper Flex I Size Range
1/0 AWG
Dimension - Bolt Size fraction
2023-05-16
Conductor Size
1/0 AWG
Dimension - Z inch
0.36 in
Conductor - Copper Flex K Size
1/0 AWG
Conductor - Copper Flex G Size
1/0 AWG
Dimension - Strip Length inch
15/16
Conductor - Copper DLO Size Range
1/0 AWG
Conductor - Copper Str Size
1/0 AWG
Dimension - Stud Size fraction
2023-05-16
Dimension - Hole Size inch
0.33 in
Dimension - B Length inch
0.87 in
Dimension - N inch
0.34 in
Dimension - D inch
0.70 in
Conductor - Copper Flex G Size Range
1/0 AWG
Dimension - Bolt Size inch
0.3125
For Stranded Copper Wire Size - Maximum
1/0 AWG

Details

Item
One-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Inspection Hole
Yes
Die Code
1,019
Color Code
Pink
Standards
CSA Certified, UL 486A-486B, UL Listed
Connector Type
Standard Barrel
Hole Center to End
0.34 in
Plate Material
Electro Tin
Peep Hole
Yes
Tongue Style
Standard
Application
For Flex Conductor
Plating Type
Tin - Electro Plated
Trade Name
HYLUGâ„¢
Conductor - Material
Copper
UL Listed
Yes
Finish Type
Tin-Plated
Type
Standard Belled Barrel, Tin Plated
Plated
Y
Physical Attribute - Number of Holes
1
Voltage Rating
35 kV
Voltage - Maximum
35000
Feature - Barrel Style
Belled
Rating - Minimum Voltage
600
Physical Attribute - Tongue Angle
Straight
Physical Attribute - Tongue Type
Standard
Conductor Type
CODE
Certification - CSA Approved
Yes
Rating - KVA
35 kV
Feature - Barrel Type
Standard
Industry Standard(s)
UL468A-468B
Die Index
12
Number of Holes
1
Contact Finish
Tin
For Wire Type
Stranded
Maximum Voltage
35 kV

Description

Compression Lug, Barrel Size Standard, Color Code Pink, Die Code 1,019, For Stud Size 5/16 in, For Stranded Copper Wire Size - Maximum 1/0 AWG, Hole Center to Center Not Applicable, Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 35 kV, Standards CSA Certified, UL 486A-486B, UL Listed, Connector Type Belled Straight Barrel, Contact Finish Tin, For Wire Size 1 AWG, 1/0 AWG, For Wire Type Stranded
