  11. Two-Hole Compression Lug, 2 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Brown
Burndy Two-Hole Compression Lug, 2 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Brown YAV2CL2NT14FX - main

Two-Hole Compression Lug, 2 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Brown

  • Mfr # YAV2CL2NT14FX

  • Zoro # G0564752

product price: $14.99
/ea

Key Features

For Wire Size
2 AWG
For Conductor Material
Copper
For Stud Size
1/4 in
Material
Copper
Barrel Size
Standard
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
YAV2CL2NT14FX
Zoro #
G0564752
UPC #
781810274217
Country of Origin
Unknown

Dimensions

For Wire Size
2 AWG
For Stud Size
1/4 in
Barrel Size
Standard
Tongue Width
0.48 in
Conductor - Copper Solid Size
2 AWG
Conductor - CopperWeld Str Size
2 A AWG;2 F AWG;2 G AWG;2 J AWG;2 K AWG;2 N AWG;2 P AWG
Dimension - Length Overall inch
2.26 in
Conductor - Copper Flex I Size
2 AWG
Dimension - Stud Size inch
44930
Conductor - Copper Flex M Size
2 AWG
Dimension - B Length fraction
5/8 in
Dimension - L Length Overall mm
57 mm
Conductor - Copper Str Navy Size
60 (37) Navy
Dimension - Z inch
0.34 in
Dimension - Bolt Hole Size inch
0.27 in
Conductor - Copper Str Size Range
2 AWG
Conductor - Copper Flex H Size
2 AWG
Dimension - N inch
0.31 in
Conductor - Copper Flex G Size
2 AWG
Conductor - Copper DLO Size
3 (125/#24) DLO;2 (150/#24) DLO
Conductor - Copper Flex K Size
2 AWG
Dimension - Outside Diameter inch
0.46 in
Dimension - B Length inch
0.63 in
Dimension - Pad Width inch
0.48 in
Conductor - Copper Str Size
2 AWG
Dimension - Strip Length inch
45246
Dimension - Hole Size inch
0.27
Conductor Size
2 AWG
Conductor - Copper Str Compact Size
"2 AWG"
Conductor - Copper Str Navy Size Range
60 (37) Navy
Conductor - Copper Flex I Size Range
2 AWG
Dimension - Bolt Size fraction
2023-01-04
Conductor - Copper Flex K Size Range
2 AWG
Dimension - Bolt Size inch
0.25
Conductor - Copper DLO Size Range
2 AWG
Conductor - Copper Flex G Size Range
2 AWG
Dimension - Hole Size mm
6.9 mm
Dimension - Hole Size fraction
2023-01-04
Conductor - Copper Flex H Size Range
2 AWG
Dimension - Stud Size fraction
2023-01-04
