Two-Hole Compression Lug, 2 AWG Max, 1/4 in Stud, Standard Barrel, Copper, Brown
- Mfr # YAV2CL2NT14FX
- Zoro # G4664861
CAD Available
product price:Â
$
18.35
/ea
Key Features
CAD Drawing
For Wire Size
2 AWG
For Conductor Material
Copper
For Stud Size
1/4 in
Material
Copper
Barrel Size
Standard
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Dimensions
- For Wire Size
- 2 AWG
- For Stud Size
- 1/4 in
- Barrel Size
- Standard
- Tongue Width
- 0.48 in
- Length
- 2.26"
- Width
- 0.48 in
- Cable Size
- 2 AWG
- Barrel Length
- Short
- Overall Length
- 2.26 in
- Overall Width
- 0.48 in
- Length (Straight Wireway)
- 2.26 in
- Hole Size
- 0.27 in
- For Stranded Copper Wire Size - Minimum
- 2 AWG
- Tongue Length
- 0.65 in
- Strip Length
- 11/16 in
- Barrel Outside Diameter
- 0.46 in
- For Stranded Copper Wire Size - Maximum
- 2 AWG
- Conductor - Copper Solid Size
- 2 AWG
- Conductor - Copper Flex H Size
- 2 AWG
- Conductor Size
- 2 AWG
- Conductor - Copper Flex K Size Range
- 2 AWG
- Conductor - Copper Flex G Size Range
- 2 AWG
- Dimension - B Length fraction
- 5/8 in
- Dimension - Bolt Size fraction
- 2023-01-04
- Dimension - Outside Diameter inch
- 0.46 in
- Dimension - Hole Size fraction
- 2023-01-04
- Dimension - Hole Size inch
- 0.27
- Conductor - Copper Flex I Size Range
- 2 AWG
- Conductor - Copper Flex K Size
- 2 AWG
- Dimension - Hole Size mm
- 6.9 mm
- Dimension - Stud Size fraction
- 2023-01-04
- Conductor - Copper Str Size Range
- 2 AWG
- Dimension - Bolt Hole Size inch
- 0.27 in
- Conductor - Copper Str Compact Size
- "2 AWG"
- Conductor - Copper Str Size
- 2 AWG
- Dimension - Z inch
- 0.34 in
- Dimension - N inch
- 0.31 in
- Conductor - CopperWeld Str Size
- 2 A AWG;2 F AWG;2 G AWG;2 J AWG;2 K AWG;2 N AWG;2 P AWG
- Dimension - Stud Size inch
- 44930
- Conductor - Copper Flex G Size
- 2 AWG
- Conductor - Copper Flex M Size
- 2 AWG
- Dimension - B Length inch
- 0.63 in
- Conductor - Copper DLO Size Range
- 2 AWG
- Dimension - Strip Length inch
- 45246
- Conductor - Copper Flex I Size
- 2 AWG
- Dimension - Bolt Size inch
- 0.25
- Conductor - Copper Str Navy Size
- 60 (37) Navy
- Dimension - Pad Width inch
- 0.48 in
- Dimension - Length Overall inch
- 2.26 in
- Conductor - Copper Flex H Size Range
- 2 AWG
- Dimension - L Length Overall mm
- 57 mm
- Conductor - Copper Str Navy Size Range
- 60 (37) Navy
- Conductor - Copper DLO Size
- 3 (125/#24) DLO;2 (150/#24) DLO
- Wire Rope Length
- 2.26 in
Description
Compression Lug, Barrel Size Standard, Color Code Brown, Die Code 10, Tongue Angle Straight, Tongue Width 0.48 in, For Conductor Material Copper, For Stud Size 1/4 in, For Stranded Copper Wire Size - Minimum 2 AWG, For Stranded Copper Wire Size - Maximum 2 AWG, Inspection Hole Yes, Hole Center to Center 0.625 in, Material Copper, Maximum Operating Temperature 194 Degrees F, Maximum Voltage 35 kV, Termination Style Crimp, Standards CSA Certified, UL 486A-486B, UL Listed, Number of Holes 2
