Two-Hole Compression Lug, 2/0 AWG Max, 1/4 in Stud, Short Barrel, Copper, Black

  • Mfr # YAV26L2NT14FX

  • Zoro # G0606226

product price:
$
25.35
/ea

Key Features

For Wire Size
2/0 AWG
For Conductor Material
Copper
For Stud Size
1/4 in
Material
Copper
Barrel Size
Short
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
YAV26L2NT14FX
Zoro #
G0606226
UPC #
781810285503
Country of Origin
Unknown

Dimensions

For Wire Size
2/0 AWG
For Stud Size
1/4 in
Barrel Size
Short
Tongue Width
0.76 in
Conductor - Copper Flex G Size
36557
Dimension - B Length fraction
13/16 in
Conductor - Copper Flex G Size Range
36557
Conductor - Copper Str Navy Size
125 (61)
Conductor - Copper DLO Size Range
2/0 (375/#24)
Conductor - Copper Flex I Size Range
36557
Dimension - Bolt Hole Size inch
0.27 in
Conductor - Copper Flex H Size Range
36557
Dimension - Strip Length inch
13/16
Dimension - N inch
0.31 in
Dimension - Pad Width inch
0.76 in
Dimension - Z inch
0.34 in
Dimension - D inch
1.28 in
Conductor - Copper Flex M Size
36557
Dimension - Length Overall inch
2.56 in
Conductor - Copper Flex K Size
36557
Dimension - Diameter Min Size inch
1.28 in
Dimension - Outside Diameter inch
0.63 in
Dimension - Bolt Size fraction
44930
Conductor - Copper Str Size Range
36557
Conductor - CopperWeld Str Size
2/0 F;2/0 G;2/0 J;2/0 K;2/0 V
Dimension - B Length inch
0.81 in
Conductor - Copper Flex K Size Range
36557
Conductor - Copper Flex H Size
36557
Conductor - Copper DLO Size
2/0 (375/#24)
Dimension - L Length Overall mm
65 mm
Conductor - Copper Flex I Size
36557
Conductor - Copper Str Size
36557
Dimension - Stud Size inch
44930

Details

Item
Two-Hole Compression Lug
For Conductor Material
Copper
Material
Copper
Tongue Angle
Straight
Die Code
13
Color Code
Black
Standards
CSA Approved
Gauge
2/0 AWG
Application
For Flex Conductors
Certification - CSA Approved
Yes
Feature - Barrel Type
Standard
Voltage - Maximum
35000
Physical Attribute - Number of Holes
2
Plated
Y
Type
YAV-L-NTFX
Die Index
13
Plating Type
Tin - Electro Plated
Rating - Minimum Voltage
600
Physical Attribute - Tongue Angle
Straight
Rating - KVA
35 kV
Barrel
Short
Bolt Hole
1/4 in
Number of Holes
2
