Shop CANARM

Backward Incline Roof Exhaust Fan, 10 hp

  • Mfr # BIRM22301000M
  • Zoro # G307963869
product price:
$
5,546.99
/ea
Additional $280.00 delivery surcharge applies per item.
See details

Key Features

Rotation
CCW
Application
Restaurant Exhaust Appliances
Bearing Type
Ball
Housing Material
Galvanized Steel
Wheel Material
Steel
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
BIRM22301000M
Zoro #
G307963869
UPC #
-
Country of Origin
Canada

Dimensions

Outlet Width
17 3/4 in
Overall Height
44 3/8 in
Outlet Height
23 9/16 in
Overall Width
48 7/16 in
Shaft Diameter
1 3/16 in
Manufacturer Warranty Length
1 yr
Inlet Diameter
23 5/8 in
Wheel Diameter
22 1/4 in
Overall Depth
35 1/2 in
Wheel Width
8 9/16 in
Fits Chest Size
2 in Drain for Easy Removal of Cleaning Solutions, Bolted Clean Outdoor, Motor Access from 3 Sides, Vented Motor and Drive Compartment Cover, with Handles, for Safety and Weather Protection, Vinyl Shaft Seal

Details

Rotation
CCW
Application
Restaurant Exhaust Appliances
Bearing Type
Ball
Housing Material
Galvanized Steel
Wheel Material
Steel
Item
Restaurant Model Backward Incline Roof Exhaust Fan
Phase
3
Motor Enclosure
Totally Enclosed Fan Cooled
Airflow @ 4.000 in SP
7,615 cfm
Corrosion Resistant
Yes
AMCA Fan Class
I
Airflow @ 0.500 in SP
10,734 cfm
Spark Resistant Construction Type
Not Rated
Motor Frame Designation
215T
Maximum Static Pressure
5 in wc
For Location
Outdoor
Standards
AMCA Air Performance Certified, NFPA 96
Features
2 in Drain for Easy Removal of Cleaning Solutions, Bolted Clean Outdoor, Motor Access from 3 Sides, Vented Motor and Drive Compartment Cover, with Handles, for Safety and Weather Protection, Vinyl Shaft Seal
For Air Type
Kitchen Roof Exhaust
Resistance Properties
Corrosion Resistant
Airflow @ 3.000 in SP
8,700 cfm
Motor Speed
1,800 RPM
Number of Discharge Positions
8
Discharge Position
Up Blast
Maximum Ambient Temperature
250 Degrees F
For Ventilation Type
Exhaust
Motor Horsepower
10 hp
Market
Commercial
Electrical Connection
Hardwired
Airflow @ 1.000 in SP
10,339 cfm
Mount Type
Roof
Wheel Type
Backward-Inclined
Airflow @ 5.000 in SP
5,583 cfm
Number of Inlets
1
Drive Type
Belt Drive
Motor Duty Class
Continuous
Housing Material Gauge
16 ga
Airflow @ 2.000 in SP
9,536 cfm
Assembly
Assembled
Airflow @ 0.750 in SP
10,533 cfm
For High-Static Pressure Applications
No
Airflow @ 1.250 in SP
10.1 cfm
Number of Speeds
Variable
Sound Level
89 dBA
Chemical Resistant
No
Outlet Shape
Square
Airflow @ 1.500 in SP
9,974 cfm
Airflow @ 3.500 in SP
8.2 cfm
Airflow @ 2.500 in SP
9,144 cfm
Maximum Inlet Air Temperature
300 Degrees F
Flange Type
Non-Flanged
Hazardous Location Specification
No
Airflow @ 0.250 in SP
10,903 cfm
Maximum Fan Speed
1.7 RPM
Airflow @ 0.000 in SP
11,013 cfm
Airflow @ 4.500 in SP
6.9 cfm
Minimum Fan Speed
1,700 RPM
Speed Controllable
Variable Speed
Nameplate Voltage
230V-460V
Hazardous Location Application
No
Airflow @ 0.125 in SP
11 cfm
Includes Drive Package
Yes
OEM Replacement
No

Description

Restaurant Model Backward Incline Roof Exhaust Fan, Wheel Type Backward-Inclined, Drive Type Belt Drive, Includes Drive Package Yes, Assembly Assembled, Wheel Diameter 22 1/4 in, Airflow @ 0.000 in SP 11,013 cfm, Airflow @ 0.125 in SP 11 cfm, Airflow @ 0.250 in SP 10,903 cfm, Airflow @ 0.500 in SP 10,734 cfm, Airflow @ 0.750 in SP 10,533 cfm, Airflow @ 1.000 in SP 10,339 cfm, Airflow @ 1.250 in SP 10.1 cfm, Airflow @ 1.500 in SP 9,974 cfm, Airflow @ 2.000 in SP 9,536 cfm
