  9. Backward Incline Roof Exhaust Fan, 2 hp
Canarm Backward Incline Roof Exhaust Fan, 2 hp BIRM1010200 - main

Backward Incline Roof Exhaust Fan, 2 hp

  • Mfr # BIRM1010200

  • Zoro # G107963854

product price: $1,814.99
/ea
Item requires special delivery charges. A $230.00 per item surcharge will be applied.

Key Features

Phase
1
Rotation
CCW
Application
Restaurant Exhaust Appliances
Motor Enclosure
Open Dripproof
Bearing Type
Ball
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
BIRM1010200
Zoro #
G107963854
UPC #
062345497228
Country of Origin
Canada

Dimensions

Manufacturer Warranty Length
1 yr
Shaft Diameter
3/4 in
Outlet Height
11 5/16 in
Overall Height
23 5/8 in
Overall Width
27 3/4 in
Outlet Width
8 1/4 in
Inlet Diameter
11 in
Overall Depth
17 1/2 in
Wheel Width
5 in
Wheel Diameter
10 1/2 in

Details

Phase
1
Rotation
CCW
Application
Restaurant Exhaust Appliances
Motor Enclosure
Open Dripproof
Bearing Type
Ball
Wheel Material
Aluminum
Housing Material
Galvanized Steel
Item
Restaurant Model Backward Incline Roof Exhaust Fan
Electrical Connection
Hardwired
Airflow @ 4.000 in SP
1,500 cfm
Drive Type
Belt Drive
Spark Resistant Construction Type
B
Number of Discharge Positions
8
Mount Type
Roof
Market
Commercial
Discharge Position
Up Blast
Wheel Type
Backward-Inclined
Airflow @ 0.500 in SP
2,329 cfm
Motor Horsepower
2 hp
Motor Speed
3,441 RPM
Housing Material Gauge
16 ga
Airflow @ 5.000 in SP
1.3 cfm
For Location
Outdoor
Motor Duty Class
Continuous
Number of Inlets
1
Airflow @ 1.000 in SP
2,300 cfm
Resistance Properties
Corrosion Resistant
Motor Frame Designation
213T; 215T; 254T
Maximum Ambient Temperature
400 Degrees F
AMCA Fan Class
I
Airflow @ 2.000 in SP
2,050 cfm
Airflow @ 3.000 in SP
1,700 cfm
For Air Type
Emergency Smoke Control
For Ventilation Type
Exhaust
Features
2 in Drain for Easy Removal of Cleaning Solutions, Bolted Clean Outdoor, Motor Access from 3 Sides, Vented Motor and Drive Compartment Cover, with Handles, for Safety and Weather Protection, Vinyl Shaft Seal
Maximum Static Pressure
5 in wc
Standards
AMCA Air Performance Certified, NFPA 96
Corrosion Resistant
Yes
Chemical Resistant
No
Maximum Inlet Air Temperature
300 Degrees F
Airflow @ 3.500 in SP
1.6 cfm
Airflow @ 4.500 in SP
1.2 cfm
For High-Static Pressure Applications
No
Number of Speeds
1
Airflow @ 0.125 in SP
2.4 cfm
Speed Controllable
No
Airflow @ 0.750 in SP
2,281 cfm
Hazardous Location Specification
No
Flange Type
Non-Flanged
Maximum Fan Speed
3.7 RPM
Airflow @ 2.500 in SP
1,950 cfm
Hazardous Location Application
No
Sound Level
80 dBA
Nameplate Voltage
115V/208V-230V
Airflow @ 1.250 in SP
2.1 cfm
Airflow @ 0.000 in SP
2,436 cfm
Includes Drive Package
Yes
Assembly
Assembled
Outlet Shape
Square
Airflow @ 1.500 in SP
2,125 cfm
Airflow @ 0.250 in SP
2,378 cfm
Minimum Fan Speed
3,700 RPM
OEM Replacement
No

Description

Restaurant Model Backward Incline Roof Exhaust Fan, Wheel Type Backward-Inclined, Drive Type Belt Drive, Includes Drive Package Yes, Assembly Assembled, Wheel Diameter 10 1/2 in, Airflow @ 0.000 in SP 2,408 cfm, Airflow @ 0.125 in SP 2.4 cfm, Airflow @ 0.250 in SP 2,375 cfm, Airflow @ 0.500 in SP 2,329 cfm, Airflow @ 0.750 in SP 2,281 cfm, Airflow @ 1.000 in SP 2,232 cfm, Airflow @ 1.250 in SP 2.1 cfm, Airflow @ 1.500 in SP 2,125 cfm, Airflow @ 2.000 in SP 2,027 cfm
