VINTAGE 30 12-in Guitar Speaker 16 OHMS

Nominal diameter: 12-in, 305mm Power rating: 60Wrms Nominal impedance: Available 8 or 16 ohm Sensitivity: 100dB Chassis type: Pressed steel Voice coil diameter: 1.75-in, 44.5mm Voice coil material: Round copper Magnet type: Ceramic Magnet weight: 50oz, 1.42kg Frequency range: 70-5000Hz Resonance frequency, Fs: 75HzBack in 1986 a new breed of hard rock player was on the rise. To meet the demands of the players & their increasingly 'hot-rodded' amplifiers, we set out to develop a modern speaker, capable of handling much more power & overdrive. To achieve this, we coupled our H magnet the closest in performance to Alnico w/a new cone & voice coil employing contemporary materials.Our most revealing speaker, the Vintage 30 features enormously detailed & complex overtones, a warm low-end, a famously rich vocal mid-range & a beautifully detailed top-end. Used singly to reveal the complexities in hand- wired boutique amps, or in quartets for a wonderfully intricate vintage 3D crunch, the Vintage 30 sound has been captured on thousands of recordings from a diverse range of notable players including Slash, Steve Stevens & Peter Frampton. Cut-out diameter: 283mm / 11.1in Diameter: 309mm / 12.2in Magnet structure diameter: 156mm / 6.1in Mounting hole dimensions: 7.9mm / 0.31in Mounting hole: PCD297mm / 11.7in
