  11. Motor, Split Ph, 1/4 HP, 1725,115V, 56Z, TEAO
This item is Discontinued.
Century Motor, Split Ph, 1/4 HP, 1725,115V, 56Z, TEAO ARB2024M

Motor, Split Ph, 1/4 HP, 1725,115V, 56Z, TEAO (Discontinued)

  • Mfr # ARB2024M
  • Zoro # G1769056
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
ARB2024M
Zoro #
G1769056
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Bolt Circle Dia.
5 13/16 in
Body Dia.
6 1/2 in
Length Less Shaft
8 1/8 in
Resilient Ring Dia.
2 1/2 in
Stud Size
#10-32
Shaft Length
1 7/8 in
Overall Length
10 1/16 in

Details

Mounting Stud Location
Shaft End
Ring to Ring Center
7 11/16 in
Motor Service Factor
1
Duty
Continuous
Motor Thermal Protection
Manual
Phase
Single
Frame
56Z
Motor Design
Split-Phase
Motor Mounting Position
All Angle
Nameplate RPM
1,725
RPM Range
1,701-1,800
Voltage
115V AC
Motor Sub Application
Direct Drive Fan/Blower
Motor Bearings
Sleeve
Full Load Amps
4.03 A
No. of Speeds
1
Motor Application
HVAC/R
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
HP
1/4
Capacitor Required
No
Item
Direct Drive Blower Motor
Motor Shaft Rotation
CW/CCW
Standards
CSA Certified, UL Recognized
Motor Enclosure Design
Totally Enclosed Nonventilated
Motor Shaft Design
Flat
Max. Ambient Temp.
40 Degrees C
Application
Blowers, Fans and Air Circulators
Includes
Resilient Base
Motor Mounting Type
Rigid Base
Hz
60 Hz
Mounting Stud Pattern
4-1/8 in x 4-1/8 in
Ins. Class
B
Usable @ 208V
No
Number of Shafts
1
Usable @ 200V
No
Weight
20 lb
Mounting Holes
4
Duty Cycle
Continuous
Motor Frame Material
Steel
Stud Quantity
4
Number of Speeds
1
Mounting
Cradle Base

Description

Direct Drive Blower Motor, Single Phase, Motor Design Split-Phase, 1/4 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, Full Load Amps 4.03 A, 56Z Frame, Usable @ 208V No, Usable @ 200V No, Motor Thermal Protection Manual, 60 Hz Hz, Motor Service Factor 1, Ins. Class B, Motor Shaft Rotation CW/CCW, Max. Ambient Temp. 40 Degrees C, Duty Cycle Continuous, Motor Enclosure Design Totally Enclosed Nonventilated, Motor Mounting Type Rigid Base, Motor Mounting Position All Angle
