  11. Split-Phase Belt Drive Motor, 1/2 HP, 48 Frame, 115V AC Voltage, 1,725 Nameplate RPM

This item is Discontinued.

Century Split-Phase Belt Drive Motor, 1/2 HP, 48 Frame, 115V AC Voltage, 1,725 Nameplate RPM GF2054

Split-Phase Belt Drive Motor, 1/2 HP, 48 Frame, 115V AC Voltage, 1,725 Nameplate RPM (Discontinued)

  • Mfr # GF2054
  • Zoro # G0702274
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
GF2054
Zoro #
G0702274
UPC #
-
Country of Origin
Mexico

Dimensions

Shaft Dia.
1/2 in
Overall Length
8 7/8 in
Body Dia.
5 5/8 in
Resilient Ring Dia.
2 1/2 in
Length Less Shaft
7 3/8 in
Shaft Length
1 1/2 in

Details

Item
Belt Drive Motor
Motor Design
Split-Phase
Motor Enclosure Design
Open Dripproof
HP
1/2
No. of Speeds
1
RPM Range
1,701-1,800
Nameplate RPM
1,725
Voltage
115V AC
Frame
48
Motor Mounting Type
Cradle Base
Motor Thermal Protection
Auto
Motor Service Factor
1.25
Voltage Compatibility
115/208-230V AC, 115/230V AC, 115V AC, 120/240V AC, 120V AC
Phase
Single
Motor Application
HVAC/R
Motor Sub Application
Belt Drive Fan/Blower
Motor Shaft Rotation
CW/CCW
Frame Material
Rolled steel
Motor Bearings
Sleeve
Standards
CSA
Ring to Ring Center
7 15/16 in
Motor Mounting Position
All Angle
Hz
60 Hz
Includes
5/8 in dia Shaft Bushing Adapter (to convert 1/2 in shaft to 5/8 in)
Max. Ambient Temp.
104 Degrees F
Full Load Amps
7.2 A
Motor Frame Material
Steel
Footnotes
92
Duty
Continuous
Ins. Class
B
Nominal Efficiency
64.5 %
Duty Cycle
Continuous
Usable @ 200V
No
Weight
18 lb
Usable @ 208V
No
Includes Shaft Bushing
Yes

Description

Belt Drive Motor, Single Phase, Motor Design Split-Phase, 1/2 HP, Nameplate RPM 1,725, No. of Speeds 1, Voltage 115V AC, 7.2 A Full Load Amps, 48 Frame, Usable @ 208V No, Usable @ 200V No, 60 Hz Hz, Motor Service Factor 1.25, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 104 Degrees F, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Open Dripproof, Motor Mounting Type Cradle Base, Motor Mounting Position All Angle, Motor Frame Material Steel
