Bus Cable, Red, PUR, 50 V, Order by the Foot
- Mfr # CF898-001
- Zoro # G608259760
product price:Â
$
3.59
/ea
Sold in multiples of 3 for $10.77
Key Features
Length
Order by the Foot
Voltage
50 V
Jacket Color
Red
Shielding
Shielded
Conductor Material
Copper
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval.
Terms apply.
Get 10% off your order
Sign up for our email list and receive your promo code via email.
Specifications
Details
- MFR #
- CF898-001
- Zoro #
- G608259760
- UPC #
- -
- Country of Origin
- Germany
- Item
- Bus Cable
- Voltage
- 50 V
- Jacket Color
- Red
- Shielding
- Shielded
- Conductor Material
- Copper
- Jacket Material
- PUR
- Standards
- 2011/65/EU, 2014/35/EU, RoHS Compliant-II, TC RU C-DE. ME77.B.01559
- Conductor Color Code
- Green, Red
- Minimum Operating Temperature - Flexible
- -40 Degrees F
- Maximum Operating Temperature
- 158 Degrees F
- Bus System
- Profibus
- Impedance
- 150 ohm
- Cable Series
- CF898
- Product Type
- Bus Cable
- Includes Ground
- No
- Minimum Operating Temperature - Fixed
- -58 Degrees F
- Resistance Properties
- Oil and Grease Resistant, UV/Sunlight Resistant
- Conductor Grouping
- (1) Pair 20 AWG
- Maximum Velocity - Unsupported
- 10 fps
- Maximum Acceleration
- 65.6 m/sq sec
- Series
- Chainflex
Description
Bus Cable, Bus System Profibus, Conductor Color Code Green, Red, Conductor Grouping (1) Pair 20 AWG, Conductor Material Copper, Impedance 150 ohm, Includes Ground No, Jacket Color Red, Jacket Material PUR, Length Order by the Foot, Maximum Acceleration 65.6 m/sq sec, Maximum Operating Temperature 158 Degrees F, Maximum Velocity - Unsupported 10 fps, Minimum Bend Radius Factor - E-Chain 15 x OD, Minimum Bend Radius Factor - Fixed 8 x OD, Minimum Bend Radius Factor - Flexible 12 x OD
