  11. 23/64 Solid Carbide 140 Degree Straight Flute Drill Chicago-Latrobe 769 Bright Carbide RHC
Chicago-Latrobe 23/64 Solid Carbide 140 Degree Straight Flute Drill Chicago-Latrobe 769 Bright Carbide RHC 78607 - main

23/64 Solid Carbide 140 Degree Straight Flute Drill Chicago-Latrobe 769 Bright Carbide RHC

  • Mfr # 78607

  • Zoro # G3743616

product price: $80.99
/ea
Free Shipping & Returns

Key Features

Overall Length
3 1/16 in
Drill Bit Point Angle
140 Degrees
Flute Length
1 3/4 in
Number of Flutes
2
Decimal Equivalent
0.359375
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
78607
Zoro #
G3743616
UPC #
662355786079
Country of Origin
United States

Dimensions

Overall Length
3 1/16 in
Drill Bit Size
23/64 in
Flute Length
1 3/4 in
Depth:Dia. Ratio
4xD
Fractional Size (In.)
23/64
Drill Bit Dimension Type
Fractional Inch
Depth x Dia. Ratio
4xD
Shank Dia.
1797/5000 in
Drill Point Length
0.0654 in
Drill Diameter Tolerance
+0.0000 in/-0.0010 in
Maximum Drilling Depth
1-7/16 in
Drill Length Class
Jobber-Length
Shank Length
1 5/16 in

Details

Item
Straight Flute Drill Bit
Drill Bit Point Angle
140 Degrees
Number of Flutes
2
Decimal Equivalent
0.359375
Drill Bit Material
Solid Carbide
Drill Bit Finish
Bright (Uncoated)
List Number
769
Material
Solid Carbide
Point Type
General Purpose
Drill Bit Grouping
Drill Bit
Finish
Uncoated
Drill Point (Deg.)
140
Application
Non-Ferrous Material, Hardened Material, Stainless Steel And Normally Limited To 2 x Diameter Drilling Depths
Helix Angle
40 Degrees
Aircraft Drill
No
Drill Bit Point Type
4 Facet Point
Series
769
Primary Material Application
Cast Iron, Hardened Steel, Nickel, Stainless Steel, Titanium
Material - Machining
Carbide
Flute Type
Straight
Measurement System
Fractional Inch
Shank Type - Machining
Straight
Finish - Machining
Bright (Uncoated)
Coolant Fed
Non-Coolant Through
Primary Material Application ISO Code
H, K, M, S
Cutting Direction
Right Hand
Standards
Not Rated
Point type
General Purpose

Description

Straight Flute Drill Bit, Drill Bit Size 23/64 in, 140 Degrees Drill Bit Point Angle, Material - Machining Carbide, Finish - Machining Bright (Uncoated), Decimal Equivalent 0.359375, Fractional Inch, 4 Facet Point Drill Bit Point Type, Flute Length 1 3/4 in
