  9. 1/2" Pistol Grip Air Impact Wrench 625 ft.-lb.
Chicago Pneumatic 1/2" Pistol Grip Air Impact Wrench 625 ft.-lb. CP6500RS - main

1/2" Pistol Grip Air Impact Wrench 625 ft.-lb.

  • Mfr # CP6500RS

  • Zoro # G3734053

product price: $470.99
/ea
Free Shipping & Returns

Key Features

Square Drive Size
1/2"
Free Speed
6,400 RPM
Air Inlet
1/4 in NPT
Handle Type
Pistol Grip
Blows per Minute
1320
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CP6500RS
Zoro #
G3734053
UPC #
015451526436
Country of Origin
Japan

Dimensions

Square Drive Size
1/2"
Drive Size - Air Tools
1/2" Square
Overall Length
7 in
Min. Hose Size
3/8 in
Anvil Length - Air Impacts
0.750"
Air Inlet Size - Air Tools
1/4" NPT
Drive Size
1/2 in Square

Details

Item
Impact Wrench
Free Speed
6,400 RPM
Air Inlet
1/4 in NPT
Handle Type
Pistol Grip
Blows per Minute
1320
Anvil Type - Air Impacts
Standard
Duty Cycle - Air Tools
Industrial Duty
Tool Weight
5.8 lb
Torque Range
125 to 502 ft.-lb.
Blows per Minute - Air Tools
1320
Duty
Heavy Duty
Housing Material
Steel
Average CFM @ 15 Second Run Time
6.20
Item - Air Impact Wrenches
Air Impact Wrench
Features
Regulator 4 Settings And One-Hand Reverse
Max. Torque
625 ft.-lb.
Retainer Type
Pin Detent
Max. Bolt Capacity
5/8 in
Anvil
Standard
CFM @ Full Load
25.0
Required Pressure
90 psi
Body Style - Air Tools
Pistol
Retainer Type - Air Impacts
Pin
Handle Material
Aluminum
Style
Pistol Grip
Standards
EN ISO 11148-6:2013, ISO-28927-2
Power Source
Air Powered
Clutch Style
Double Rocking Dog
Duty Rating
Industrial Duty
Impact Rated
Yes
Vibration Level
8.0 m/sq sec
Impact Sound Level
107 dB
Impacts per Minute
1,320
Built-In Light
No
Tool Style
Compact
Max. Air Pressure
90 psi
Air Consumption
25 cfm
Min. Air Pressure
90 psi
Drive Type
Standard
Fastening Torque
502 ft-lb
Exhaust Location
Bottom
Air Pressure
90 psi
Number of Speed Settings
4
Breakaway Torque
625 ft-lb
Power to Weight Ratio
107.8 ft-lb/lb

Description

Impact Wrench, Power Source Air Powered, Air Consumption 25 cfm, Air Inlet 1/4 in NPT, Air Pressure 90 psi, Max. Air Pressure 90 psi, Min. Air Pressure 90 psi, Min. Hose Size 3/8 in, Exhaust Location Bottom, Duty Rating Industrial Duty, Breakaway Torque 625 ft-lb, Fastening Torque 502 ft-lb, Free Speed 6,400 RPM, Impact Rated Yes, Impact Sound Level 107 dB, Impacts per Minute 1,320, Number of Speed Settings 4, Power to Weight Ratio 107.8 ft-lb/lb, Max. Bolt Capacity 5/8 in
