Surge Protection Device, 3 Phase, 277/480V, 4 Wires
Mfr # DS44S-400
Zoro # G102664305
product price: $288.99
/ea
Free Shipping & Returns
Key Features
Mounting Style
Din Rail
Phase
3
Voltage
277/480V
Number of Wires
4 Wires
Modes of Protection
L-L, L-N, L-G, N-G
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
DS44S-400
Zoro #
G102664305
UPC #
-
Country of Origin
China
Dimensions
Length
90 mm
Depth
72 mm
Width
67 mm
Details
Item
Surge Protection Device
Mounting Style
Din Rail
Phase
3
Voltage
277/480V
Voltage Protection Rating
2500V/1500V/1500V/1500V
Number of Wires
4 Wires
Modes of Protection
L-L, L-N, L-G, N-G
Max. Surge Current per Mode
40kA
Nominal Discharge Current
20 kA
Short Circuit Current Rating
100kA
Modular
Yes
Max. Continuing Operating Voltage
680V/420V/420V/420V
IP Rating
IP20
Enclosure Material
Thermoplastic
Standards
UL 1449 Type 1
