Surge Protection Device, 3 Phase, 480V, 3 Wires
Mfr # DS43S-480
Zoro # G602664256
product price: $209.99
/ea
Free Shipping & Returns
Key Features
Mounting Style
Din Rail
Phase
3
Voltage
480V
Number of Wires
3 Wires
Modes of Protection
L-L, L-G
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
DS43S-480
Zoro #
G602664256
UPC #
-
Country of Origin
China
Dimensions
Length
90 mm
Depth
54 mm
Width
67 mm
Details
Item
Surge Protection Device
Mounting Style
Din Rail
Phase
3
Voltage
480V
Voltage Protection Rating
4000V/1800V
Number of Wires
3 Wires
Modes of Protection
L-L, L-G
Max. Surge Current per Mode
40kA
Nominal Discharge Current
20 kA
Short Circuit Current Rating
100kA
Modular
Yes
Max. Continuing Operating Voltage
550V
IP Rating
IP20
Enclosure Material
Thermoplastic
Standards
UL 1449 Type 1
