  6. 3" X 1-1/4" Non-Marking Polyolefin Swivel Caster, No Brake, Loads Up To 200 lb
Colson 3" X 1-1/4" Non-Marking Polyolefin Swivel Caster, No Brake, Loads Up To 200 lb 2.03356.52 - main

3" X 1-1/4" Non-Marking Polyolefin Swivel Caster, No Brake, Loads Up To 200 lb

  • Mfr # 2.03356.52

  • Zoro # G7812396

product price:  $19.59
/ea

Key Features

Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Polyolefin
Mounting Height
4-1/8 in
Load Rating
200 lb
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
2.03356.52
Zoro #
G7812396
UPC #
-
Country of Origin
China

Dimensions

Mounting Height
4-1/8 in
Mounting Plate Size
2 1/2 in x 3 5/8 in
Mounting Plate Thickness
5/32 in
Wheel Dia.
3 in
Wheel Width
1 1/4 in
Mounting Bolt Dia.
5/16 in
Mounting Plate Width
2 1/2 in
For Axle Dia.
3/8 in
Inside Slot Spacing - Width
1.75 in
Outside Slot Spacing - Length
3.063 in
Outside Slot Spacing - Width
1.75 in
Mounting Plate Length
3 5/8 in
Inside Slot Spacing - Length
2.813 in

Details

Item
Swivel Caster
Caster Sub-Type
Swivel
System of Measurement
Inch
Wheel/Tread Material
Polyolefin
Load Rating
200 lb
Caster Mounting Type
Plate
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Number of Wheels
1
Outside Bolt Hole Spacing
1-3/4 in X 3-13/16 in
Caster Plate Hole Pattern
C
Series
2
Application
Store Fixtures, Stoage Equipment, Utility Carts, Institutional Equipment, Office Equipment, Food Service, Material Handling Equipment, Hospitality Carts
Wheel/Tread Hardness Rating
Hard
Non-Marking
Yes
Includes Thread Guards
No
Wheel Core Material
Polyolefin
Wheel Bearing Type
Ball
Caster Brake Type
No Brake
Swivel Raceway Type
Double Ball
Load Rating Range
0 to 299 lb
Operating Temperature Range
-45 Degrees to 180 Degrees F
Caster Stem Type
Top Plate
Core Color
Black
Wheel Core Type
Solid
Swivel Lock Type
No Lock Included
Frame Finish
Zinc Plated
Inside Bolt Hole Spacing
1-3/4 in X 2-13/16 in
Load Capacity - Maximum
200 lb
Wheel Hardness Rating
70 Shore D
Mounting Hole Type
Slot
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel, Tile, Wood
Mounting Plate Shape
Rectangle

Description

Swivel, Plate Caster, Load Rating 200 lb, Swivel Lock Type No Lock Included, Wheel Dia. 3 in, Wheel Width 1 1/4 in, Wheel/Tread Material Polyolefin, Wheel Core Material Polyolefin, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
