Colson 4" X 1-1/4" Non-Marking Rubber Performa (Flat) Swivel Caster, No Brake, Loads Up To 300 lb 2.04256.445 - main

4" X 1-1/4" Non-Marking Rubber Performa (Flat) Swivel Caster, No Brake, Loads Up To 300 lb

  • Mfr # 2.04256.445

  • Zoro # G7810810

product price:  $33.35
/ea

Key Features

Application
Store Fixtures, Stoage Equipment, Utility Carts, Institutional Equipment, Office Equipment, Food Service, Material Handling Equipment, Hospitality Carts
System of Measurement
Inch
Wheel/Tread Hardness Rating
Soft
Tread Shape
Standard
Caster Brake Type
No Brake
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
2.04256.445
Zoro #
G7810810
UPC #
-
Country of Origin
China

Dimensions

Mounting Bolt Dia.
5/16 in
Mounting Plate Size
2 1/2 in x 3 5/8 in
Wheel Dia.
4 in
Mounting Height
5-1/8 in
Wheel Width
1 1/4 in
Inside Slot Spacing - Length
2.813 in
Mounting Plate Thickness
5/32 in
Inside Slot Spacing - Width
1.75 in
Mounting Plate Length
3 5/8 in
Mounting Plate Width
2 1/2 in
For Axle Dia.
3/8 in
Outside Slot Spacing - Width
1.75 in
Outside Slot Spacing - Length
3.063 in

Details

Application
Store Fixtures, Stoage Equipment, Utility Carts, Institutional Equipment, Office Equipment, Food Service, Material Handling Equipment, Hospitality Carts
System of Measurement
Inch
Wheel/Tread Hardness Rating
Soft
Tread Shape
Standard
Caster Brake Type
No Brake
Inside Bolt Hole Spacing
1-3/4 in X 2-13/16 in
Caster Stem Type
Top Plate
Wheel Core Material
Polypropylene
Item
Swivel Caster
Core Color
Grey
Includes Thread Guards
No
Swivel Raceway Type
Double Ball
Number of Mounting Holes
4
Wheel Bearing Type
Ball
Wheel/Tread Material
Rubber
Caster Frame Material
Steel
Outside Bolt Hole Spacing
1-3/4 in X 3-13/16 in
Load Rating
300 lb
Number of Wheels
1
Series
2
Non-Marking
Yes
Caster Sub-Type
Swivel
Wheel Core Type
Solid
Swivel Lock Type
No Lock Included
Caster Plate Hole Pattern
C
Operating Temperature Range
-45 Degrees to 180 Degrees F
Frame Finish
Zinc Plated
Caster Mounting Type
Plate
Load Rating Range
300 to 999 lb
Load Capacity - Maximum
300 lb
Wheel Hardness Rating
65 Shore A
For Surface Type
Asphalt, Ceramic, Metal Scrap, Rubber, Steel, Tile, Vinyl, Wood
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
Caster Features
Debris-Resistant, Quiet-Roll, Shock-Absorbing

Description

Swivel, Plate Caster, Load Rating 300 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 1 1/4 in, Wheel/Tread Material Rubber, Wheel Core Material Polypropylene, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
