  6. 6" X 3" Ductile Rigid Caster, No Brake, Loads Up To 5400 lb
Colson 6" X 3" Ductile Rigid Caster, No Brake, Loads Up To 5400 lb 410FR06501R - main

6" X 3" Ductile Rigid Caster, No Brake, Loads Up To 5400 lb

  • Mfr # 410FR06501R

  • Zoro # G2086646

product price:  $195.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Rigid
Wheel/Tread Material
Ductile Iron
Caster Brake Type
No Brake
Wheel Dia.
6 in
Wheel Width
3 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
410FR06501R
Zoro #
G2086646
UPC #
-
Country of Origin
United States

Dimensions

Wheel Dia.
6 in
Wheel Width
3 in
Mounting Height
10-1/2 in
Mounting Plate Size
5 1/4 in x 7 1/4 in
Mounting Plate Thickness
3/8 in
Mounting Bolt Dia.
1/2 in
Overall Height
10-1/2in
Outside Slot Spacing - Length
6.125 in
Inside Slot Spacing - Length
5.25 in
For Axle Dia.
3/4 in
Mounting Plate Width
5 1/4 in
Mounting Plate Length
7 1/4 in
Outside Slot Spacing - Width
4.125 in
Inside Slot Spacing - Width
3.375 in

Details

Item
Rigid Caster
Caster Sub-Type
Rigid
Wheel/Tread Material
Ductile Iron
Caster Brake Type
No Brake
Load Rating
5400 lb
Wheel Bearing Type
Roller
Wheel/Tread Color
Black
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Cast Iron
Core Color
Grey
Non-Marking
No
Number of Wheels
1
Outside Bolt Hole Spacing
3-3/8 in X 5-1/4 in
Inside Bolt Hole Spacing
2-7/16 in X 4-15/16 in
Caster Plate Hole Pattern
A
Application
Conveyor Drawn Tow Trucks, Heavy Duty Baker Racks, Production Dollies, Heavy Duty Dough Troughs
Frame Finish
Zinc Plated
Caster Brake Included
No
Wheel Color
Black
Replacement Wheel
Mfr. No. FR0850116G
Extended Lead
No
Caster Temp. Range Available
Yes
Thread Guards
No
Caster Stem Type
Top Plate
Includes Thread Guards
No
Wheel Core Material
Ductile Iron
Swivel Lock Type
No Lock Included
Wheel/Tread Hardness Rating
Hard
Swivel Construction
Kingpinless
Load Rating Range
3000 to 5999 lb
Compatible With
FR0850116G
Load Capacity - Maximum
5,400 lb
Mounting Hole Type
Slot
Wheel Core Type
Solid
For Surface Type
Asphalt, Grease, Steel
Mounting Plate Shape
Rectangle
Operating Temperature Range
Up to 800 Degrees F
Operating Temperature - Maximum
800 Degrees F

Description

Rigid, Plate Caster, Load Rating 5400 lb, Swivel Lock Type No Lock Included, Wheel Dia. 6 in, Wheel Width 3 in, Wheel/Tread Material Iron, Wheel Core Material Iron, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Donut
